Sonance VXXT6 – Outdoor Extreme 6-Inch Rectangle In-Wall Speaker

Product Overview

The Sonance VXXT6 is a 6.5-inch, 6-inch-rectangle-format in-wall speaker built for outdoor and other exposed environments where a standard architectural speaker will not hold up. It pairs a waterproof cloth-dome tweeter with a Santoprene-surround woofer behind an IP66-rated enclosure, and is finished in Brilliant White (Satin) with Sonance's XPC grille retention. It is intended for integrators and contractors specifying weatherproof background or foreground audio for covered and semi-exposed spaces.

Product Description

The VXXT6 uses a 1.0-inch waterproof, Ferrofluid-cooled cloth-dome tweeter above a 6.5-inch polypropylene-cone woofer with a Santoprene surround, delivering an 8-ohm load rated at 5W minimum and 125W maximum RMS with a 45Hz–20kHz (±3dB) frequency response and 89dB sensitivity. The IP66 rating means the enclosure is protected against dust ingress and powerful water jets from any direction, which is the level of protection integrators look for on covered patios, soffits, and other outdoor-adjacent locations. Physically, the speaker measures 7.77" W x 11.66" H x 3.4" D with a 6.94" x 10.75" cutout and a 3.29" mounting depth, and weighs 11.02 lbs. Grille retention uses the same XPC (Extreme Post-Capture) magnetic system found on other Sonance Extreme-series products, so the same micro trim and trimless grille accessories carry over across a project. For integrators laying out a full exterior zone, the VXXT6 is commonly paired with matching outdoor speaker and grille adapters to keep bezel styling consistent from the patio to the ceiling. It is a passive speaker, so it requires an appropriately rated amplifier channel sized to its 8-ohm impedance and 125W maximum power handling.

Key Features

• Waterproof Tweeter — 1.0-inch Ferrofluid-cooled cloth-dome tweeter designed for moisture exposure.
• Santoprene Woofer Surround — 6.5-inch polypropylene woofer with a weather-resistant Santoprene surround.
• IP66 Weather Rating — Protected against dust ingress and high-pressure water jets for outdoor and covered installs.
• 125W Power Handling — 8-ohm rating from 5W minimum to 125W maximum RMS suits a range of amplifier channels.
• XPC Grille Retention — Magnetic Extreme Post-Capture grille system resists wind and power-washer shear force.
• Compact Rectangle Footprint — 6.94" x 10.75" cutout and 3.29" mounting depth suit shallow wall cavities.

Typical Applications

• Covered patios, porches, and outdoor kitchens
• Soffits and exterior walls exposed to weather
• Pool areas and other wet or humid environments

Technical Specifications

Frequently Asked Questions

Is the Sonance VXXT6 safe for direct rain exposure?

The IP66 rating covers dust and powerful water jets from any direction, which suits covered or semi-exposed locations; check local code and Sonance's mounting guidance for fully unprotected, direct-rain locations.

What amplifier power does the VXXT6 need?

It is an 8-ohm speaker rated from 5W minimum to 125W maximum RMS, so it should be driven by an amplifier channel sized within that range at 8 ohms.

Can the VXXT6 grille be repainted or laser-printed?

Sonance offers grille painting and laser-printing services on Visual Experience Series products; confirm current options and lead time with Creation Networks before ordering.

Does the VXXT6 come with a mounting bracket?

It installs using Sonance's standard in-wall mounting hardware for the Extreme rectangle format; a compatible bracket or enclosure should be confirmed for new-construction versus retrofit installs.

Is the VXXT6 sold as a single speaker or a pair?

Sonance lists Visual Experience Series speakers individually by SKU; confirm quantity per box with Creation Networks before ordering a stereo pair.

What grille styles are available for the VXXT6?

It uses the XPC (Extreme Post-Capture) retention system, which supports micro trim and trimless grille options in the same Brilliant White (Satin) finish.
