ViewSonic VB‑BLW‑005 BalanceBox 650 Wall Mount (65″‑75″ Display Range)

Product Overview

The ViewSonic VB-BLW-005 BalanceBox 650 Wall Mount is a professional height-adjustable wall mount engineered for 65" to 75" large interactive displays weighing between 147.7 and 280 lbs, delivering 25.6 inches of spring-tension vertical adjustment without any electrical power. Designed for AV integrators and facilities managers who require ergonomic display positioning in wall-mounted configurations, this mount transforms a fixed installation into an adjustable one — enabling height changes from seated to standing viewing with minimal effort. Ideal for classrooms, corporate boardrooms, and shared collaborative spaces.

Product Description

The VB-BLW-005 belongs to the BalanceBox 650 series wall mount lineup and is optimized for 65" and 75" interactive panels at the higher end of the 650 series weight range — supporting loads from 147.7 lbs up to 280 lbs. The spring-tension mechanism provides 25.6" of smooth vertical travel, allowing display height adjustments for different user heights and audience configurations without any electrical connection. Mount dimensions are approximately 36.4" × 41.7" × 6.3" depth with a net weight of approximately 139.9 lbs. The slim 6.3" depth profile keeps the installation low-profile against the wall while providing full adjustment range. This mount is particularly valuable in dedicated instructional spaces where teachers and presenters of varying heights need reliable height customization, or in corporate environments with adjustable-height meeting configurations. The black powder-coat steel construction blends into professional interiors.

Key Features

• Load Capacity: 147.7 to 280 lbs (67–127 kg) — Highest-capacity wall mount in the BalanceBox 650 series.
• 25.6" Spring-Tension Height Adjustment — Power-free ergonomic repositioning for seated and standing configurations.
• Compatible Display Size: 65" to 75" — Optimized for the most common large-format classroom and boardroom panel sizes.
• Slim 6.3" Wall Profile — Low-profile installation for space-efficient wall mounting.
• No Electricity Required — Eliminates power dependency for height adjustment; works in any installation.
• Black Powder-Coat Steel — Professional finish for corporate and educational environments.

Technical Specifications

Frequently Asked Questions

Q: What wall structure is required for the VB-BLW-005?
A: The mount requires a structurally sound wall capable of supporting the combined weight of the mount (139.9 lbs) plus the display load (up to 280 lbs). For walls without adequate studs, add a VB-BFS-002 floor support as a supplemental backer.

Q: Does this mount require electricity for height adjustment?
A: No. The spring-tension mechanism is fully manual and requires no electrical connection.

Q: What is the difference between VB-BLW-005 and VB-BLW-004?
A: The VB-BLW-005 supports heavier displays (up to 280 lbs) vs. the VB-BLW-004 (up to 154 lbs). Both cover 65"–75" display sizes with identical 25.6" height adjustment.

Q: What VESA patterns are supported?
A: Uses BalanceBox 650-series brackets. Consult ViewSonic's VESA compatibility guide for your specific display model.

Q: Is a floor support needed with this wall mount?
A: Not required, but the VB-BFS-002 (BalanceBox 650 Floor Support) can be used when wall stud spacing does not align with the mount's attachment points.
