ViewSonic VB‑BLW‑004 BalanceBox 650‑80 Wall Mount
ViewSonic VB‑BLW‑004 BalanceBox 650‑80 Wall Mount is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
ViewSonic VB‑BLW‑004 BalanceBox 650‑80 Wall Mount
Product Overview
The ViewSonic VB-BLW-004 BalanceBox 650-80 Wall Mount is a height-adjustable wall mount designed for 55" to 75" interactive displays weighing 75 to 154 lbs, providing 25.6 inches of smooth spring-tension vertical adjustment without electricity. Engineered for AV integrators and education technology coordinators who need ergonomic, space-efficient wall installations, this mount delivers professional-grade height flexibility in classrooms, enterprise meeting rooms, and collaborative spaces. The slim 6.3" depth profile keeps the installation close to the wall for a clean, low-profile appearance.
Product Description
The VB-BLW-004 is part of the BalanceBox 650-80 series and supports display loads from 75 lbs to 154 lbs — the standard weight range for 65" and 75" interactive flat panels with typical peripheral attachments. The spring-tension mechanism provides 25.6" of vertical height adjustment, allowing display positioning for different audience heights and configurations without any power source. At approximately 6.3" depth and 139.9 lbs net weight, the mount provides a stable, low-profile wall installation. Black powder-coat steel finish blends professionally into both educational and corporate environments. The VB-BLW-004 is ideally suited for dedicated classroom walls, corporate training rooms, and meeting spaces where the display position needs to be adjusted based on presenter height or audience configuration. It requires structural wall support adequate for the combined mount and display weight.
Key Features
- Load Capacity: 75 to 154 lbs (34–70 kg) — Matches standard 65" and 75" interactive panel weights.
- 25.6" Spring-Tension Height Adjustment — Power-free ergonomic repositioning for varied user heights.
- Compatible Display Size: 55" to 75" — Covers the most common large-format interactive panel sizes.
- Slim 6.3" Depth — Low-profile installation for space-efficient wall mounting.
- No Electricity Required — Works in any wall installation without power connections.
- Black Powder-Coat Steel — Durable, professional finish for shared spaces.
Technical Specifications
| Load Capacity | 75 – 154 lbs (~34 – 70 kg) |
| Height Adjustment Range | 25.6" (~650 mm) |
| Compatible Display Size | 55" – 75" diagonal |
| Adjustment Mechanism | Manual spring-tension (no electricity required) |
| Mount Depth | Approx. 6.3" (~160 mm) |
| Net Weight | Approx. 139.9 lbs (~63 kg) |
| Mount Type | Wall mount |
| Series | BalanceBox 650-80 |
| Color | Black |
| SKU | VB-BLW-004 |
Frequently Asked Questions
Q: What is the weight difference between VB-BLW-004 and VB-BLW-005?
A: VB-BLW-004 supports up to 154 lbs; VB-BLW-005 supports up to 280 lbs. Both cover 65"–75" displays with the same 25.6" adjustment range.
Q: Does height adjustment require electricity?
A: No. The spring-tension mechanism is fully manual and requires no power at any time.
Q: What VESA patterns are supported?
A: Uses BalanceBox 650-80 series brackets. Check ViewSonic's VESA compatibility guide for your panel model.
Q: What wall structure is required?
A: The wall must support the combined weight of mount (139.9 lbs) and display (up to 154 lbs). For weak or unsupported walls, consider adding a VB-BFS-002 floor support.
Q: Is the VB-BLW-004 compatible with the 400-series accessories?
A: No — this is a 650-series mount. For 400-series compatibility, see VB-BLW-001, -002, or -003.
