ViewSonic LS751HD 5000 ANSI Lumens 1080p Laser Installation Projector
Product Overview
The ViewSonic LS751HD is a 5,000 ANSI lumen 1080p laser installation projector engineered for large-venue commercial AV deployments including auditoriums, boardrooms, and houses of worship. Built on 2nd-generation laser phosphor technology with a 30,000-hour rated light source, it eliminates lamp replacement costs while delivering consistent brightness across a 30–300" throw range. The 1.6x optical zoom, vertical lens shift, and 360° projection flexibility make it well-suited for fixed-installation integrators working with demanding ceiling or floor mounts.
Product Description
The LS751HD belongs to ViewSonic's Luminous Superior Series, targeting commercial and institutional integrators who require lamp-free reliability without sacrificing brightness. At 5,000 ANSI lumens and 1920x1080 native resolution, it handles ambient-lit environments from lecture halls to large conference rooms with equal competence. The 1.4–2.24:1 throw ratio positions this projector for standard installation distances — at 10.2 feet it fills a 100" screen — with 1.6x optical zoom providing meaningful flexibility without repositioning the mount. HDMI 2.0b with HDR10/HLG support ensures 4K source material is handled correctly, accepting content up to 3840x2160 while projecting at 1080p. The dual ±30° H/V keystone correction and 4-corner adjustment cover common installation geometry challenges, while portrait mode and 360° projection open non-traditional deployment angles for digital signage and architectural applications. The sealed optical path and mercury-free design reduce maintenance overhead compared to lamp-based alternatives. A 30W stereo speaker system is integrated, reducing the need for external audio in smaller venues. At 9.9 lbs, it is light enough for single-person ceiling mount installation. Power consumption runs 240W at full brightness, dropping below 0.5W in standby.
Key Features
- 5,000 ANSI Lumens — Delivers bright, washout-resistant images in ambient-lit auditoriums and conference rooms.
- 2nd-Generation Laser Phosphor — 20,000-hour full-brightness / 30,000-hour eco-mode lifespan with no lamp replacement cycle.
- 1.6x Optical Zoom + Vertical Lens Shift — Installation flexibility without moving the mount; lens shift range is -18 to 0%.
- HDMI 2.0b with HDR10/HLG — Accepts 4K HDR source signals; HDCP 1.4 compliant.
- H/V Keystone ±30° + 4-Corner Correction — Handles off-axis installation geometries with precision.
- 360° Projection + Portrait Mode — Supports floor, ceiling, rear, and rotated installations for signage and architectural use.
- 30W Stereo Speakers — Integrated audio suitable for small-to-medium venues.
- 10-Bit Color Depth — 1.07 billion colors, 3,000,000:1 dynamic contrast ratio.
- Mobile App Compatible — Remote management via ViewSonic's projector app.
Typical Applications
- Auditorium and large-venue fixed installations
- Corporate boardrooms and executive conference rooms
- Houses of worship with permanent projection setups
- University lecture halls and training rooms
- Government briefing rooms and command centers
- Architectural projection and digital signage installations
Technical Specifications
| Native Resolution | 1920 x 1080 (1080p) |
| Brightness | 5,000 ANSI Lumens |
| Dynamic Contrast Ratio | 3,000,000:1 |
| Color Depth | 10-bit (1.07 billion colors) |
| Light Source | Laser Phosphor (2nd Gen) |
| Light Source Life | 20,000 hrs (full) / 30,000 hrs (eco) |
| Throw Ratio | 1.4–2.24:1 (100" @ 10.2 ft) |
| Projection Size | 30" – 300" |
| Throw Distance | 3.05 – 48.82 ft (0.93 – 14.88 m) |
| Optical Zoom | 1.6x |
| Lens Shift (Vertical) | -18 to 0% |
| Keystone Correction | H/V ±30°; 4-corner adjustment |
| HDR Support | HDR10 / Hybrid Log Gamma (HLG) |
| Supported Resolutions | 640x480 – 3840x2160 |
| Connectivity | HDMI 2.0b (HDCP 1.4) |
| Speaker | 30W stereo |
| Noise Level | 32 dB (full) / 29 dB (eco) |
| Power Consumption | 240W (full) / <0.5W (standby) |
| Dimensions (W x H x D) | 13.3 x 5.2 x 10.4" (337 x 131.5 x 265 mm) |
| Weight | 9.9 lbs (4.5 kg) |
Frequently Asked Questions
Q: Does the LS751HD include a lens, or is a separate lens required?
A: The LS751HD ships with a lens included. The 1.6x optical zoom lens is factory-installed, so no separate lens purchase is needed for standard installations.
Q: What is the minimum throw distance for a 100" image?
A: With the throw ratio of 1.4:1, a 100" screen requires approximately 10.2 feet (3.1 m) from projector to screen at the minimum zoom setting. The 2.24:1 maximum ratio extends that to roughly 16.3 feet.
Q: Can the LS751HD be installed in portrait or inverted orientation?
A: Yes. The LS751HD supports 360° projection including portrait mode, making it suitable for non-standard installation orientations such as floor projection or rotated digital signage.
Q: Does this projector support 4K sources?
A: The LS751HD accepts 4K input via HDMI 2.0b and supports HDR10/HLG metadata. It displays content at 1080p native resolution.
Q: How long does the laser light source last?
A: Rated at 20,000 hours at full brightness and 30,000 hours in eco mode. Unlike lamp projectors, the laser phosphor source does not require periodic replacement under normal operating conditions.
Q: Is the LS751HD compatible with control systems like Crestron or AMX?
A: The LS751HD supports RS-232 serial control for integration with third-party control systems. Check the ViewSonic integration guide for specific command sets.
Q: What ceiling mount options are compatible with the LS751HD?
A: The projector uses a standard mounting interface. ViewSonic offers compatible ceiling mounts, and integrators should confirm the mount specifications against the projector's 9.9 lb weight.
