ViewSonic LDC027‑150 P1.5 Customizable All‑in‑One LED Display
The ViewSonic LDC027‑150 is a high‑precision LED display module designed for scalable video wall installations. Featuring a 1.5 mm (actually ~1.56 mm) pixel pitch and native 16:9 aspect‑ratio cabinet, it enables straightforward configuration of 4K or Full HD layouts. The all‑in‑one design integrates power, control, and display modules into a slim 31 mm deep cabinet, allowing for near‑seamless screen‑to‑body ratios and clean architectural integration. Durability is built in via Glue‑on‑Board (GOB) surface treatment and front‑rated IP54 ingress protection, making this suited for public spaces like lobbies, retail, transportation hubs, and enterprise signage walls.
Installation benefits include front maintenance access, LAN‑based centralized control, and the flexibility to build ultra‑wide or tall screen configurations thanks to its modular nature. The LDC027‑150 is ideal for environments where high image fidelity, design integration and continuous operation matter.
Features Chart
| Feature | Benefit |
|---|---|
| ≈ 1.5 mm (1.56 mm) pixel pitch | Delivers fine‑detail visuals suitable even at closer viewing distances |
| All‑in‑one slim cabinet (31 mm) | Simplifies installation and provides a sleek look with minimal depth |
| GOB surface treatment + IP54 front | Enhanced durability in public or high‑traffic installations |
| Native 16:9 cabinet aspect ratio | Enables easy alignment to 4K or Full HD layouts for signage or walls |
| LAN‑based centralized control | Facilitates efficient management of multiple modules across a wall |
| Front‑access modules | Simplifies maintenance without needing to remove the display setup |
Specifications Table
| Specification | Detail |
|---|---|
| Cabinet size | 27″ diagonal per module (~600 × 337.5 mm) |
| Pixel pitch | ~1.56 mm |
| Brightness (typical) | 600 nits |
| Static contrast ratio | ~6,500 : 1 |
| Viewing angles | ~170° horizontal / ~170° vertical |
| Ingress protection (front) | IP54 |
| LED lifetime (typical) | ~100,000 hours |
| Cabinet depth | ~31 mm |
| Native cabinet resolution | 384 × 216 pixels (per module) |
| Supported wall resolution | Up to 7,680 px width or 1,920 px height (varies by configuration) |
| Operation environment | Designed for commercial signage and 24/7 usage |
