ViewSonic IFP105UW 105" interactive, Ultra-wide Display, 21:9 Aspect Ratio

Product Overview

The ViewSonic IFP105UW is a 105" 5K ultra-wide interactive flat panel display built for corporate conference rooms, huddle spaces, and higher education environments that require a large-format, touch-enabled collaboration surface optimized for Microsoft Teams Rooms and Front Row workflows. With a native 5120 x 2160 resolution across a 21:9 aspect ratio LCD panel, it provides an expansive, high-detail canvas for digital whiteboarding, multi-source content sharing, and hybrid meeting scenarios. Up to 40-point infrared multi-touch with intelligent palm rejection delivers a natural, low-latency writing experience using both finger and stylus input. The integrated 47W soundbar with beamforming microphone array enables in-room participants and remote attendees to hear and be heard clearly without external audio hardware.

Product Description

The IFP105UW is built on ViewBoard OS with an octa-core CPU (Cortex-A76 x4 + A55 x4), Mali-G610 GPU, 8GB LPDDR RAM, and 128GB eMMC 5.0 storage. This processing configuration handles native Android-based collaboration applications, myViewBoard digital whiteboarding software, and CMS-based content management without a connected PC. For Windows-based workflows, the display includes an OPS slot for optional slot-in PC modules, making it compatible with Microsoft Teams Rooms hardware bundles. vCast software enables simultaneous multi-user wireless content sharing and annotation from Windows, Mac, iOS, and Android devices; AirPlay, Google Cast, and browser-based casting are all supported. USB-C ports (two, each providing 60W) enable single-cable connection of a laptop with video, data, and power over a single cable. Three HDMI 2.0 inputs and one HDMI 2.1 input accommodate all current-generation video sources. The 9H anti-glare tempered glass surface protects the touch array while reducing reflections in mixed-light environments. Wi-Fi 6 (802.11ax) and Bluetooth 5.2 are available via the optional VB-WIFI-004 adapter. Two Ethernet (RJ45) ports provide wired LAN connectivity for both the Android OS and an attached PC simultaneously. RS-232 and LAN control enable integration with Crestron, AMX, and other commercial AV control systems. ViewSonic Manager is built in for remote device management, firmware scheduling, and fleet monitoring across multiple displays. The 4,000:1 static contrast ratio and 400 nits brightness ensure image clarity in typical conference room lighting conditions.

Key Features

• 105" 5K Ultra-Wide (5120 x 2160) at 21:9 — Massive collaboration canvas optimized for Microsoft Teams Front Row and side-by-side multi-source content display.
• Microsoft Teams Rooms / Front Row Certified — Native support for Microsoft Teams Room and Front Row optimizes hybrid meeting inclusivity and participant visibility.
• 40-Point IR Multi-Touch with Palm Recognition — Up to 40 simultaneous touch points (Windows) with intelligent palm rejection; 2mm and 8mm tip stylus detection and 10-15mm finger detection.
• 47W Soundbar with Beamforming Microphone Array — 16W x 2 speakers plus 15W subwoofer; 8-element beamforming microphone array with full duplex echo cancellation for in-room and remote audio clarity.
• Dual USB-C (60W Each) — Single-cable laptop connection with video, data, and 60W power delivery per port; eliminates adapter clutter on the conference table.
• ViewBoard OS + OPS Slot — Android-based ViewBoard OS with 8GB RAM and 128GB storage for native apps; OPS slot accommodates Windows-based PC modules for full Microsoft Teams Rooms deployments.
• vCast Multi-User Wireless Sharing — Simultaneous screen sharing and annotation from multiple devices; AirPlay, Google Cast, and browser-based casting supported.
• myViewBoard Digital Whiteboarding — Cloud-based whiteboard with SSO, cloud drive integration, QR code sharing, and annotation tools; sessions persist and are shareable after the meeting.
• Wi-Fi 6 (802.11ax) via VB-WIFI-004 — Optional USB Wi-Fi adapter adds Wi-Fi 6 and Bluetooth 5.2 wireless connectivity.
• 9H Anti-Glare Tempered Glass Surface — Protects touch array and reduces ambient light reflections in mixed-lighting conference rooms.
• Dual Ethernet (RJ45) — Separate LAN ports for Android OS and attached PC; supports 10/100/1000Mbps on the primary port.
• RS-232 + LAN Control — Compatible with Crestron, AMX, and other commercial AV control systems for enterprise deployments.
• ViewSonic Manager Built-In — Cloud-based fleet management for scheduling updates, monitoring status, and managing settings across multiple displays.
• VESA 1000x400 — Compatible with standard large-format wall mounts; 201.5 lbs net weight.

Typical Applications

• Microsoft Teams Rooms and Zoom Rooms medium and large conference rooms
• Corporate boardrooms and executive briefing centers
• Higher education lecture halls and collaborative classrooms
• Government and municipal meeting chambers
• Hybrid collaboration studios and video production suites
• Training centers with multi-user digital whiteboarding requirements
