ViewSonic TeamJoin™ TRS10 With Display Bundle – Model CDE6530‑MTR (65″ 4K Display, Compute Engine MPC310‑W31‑TU & Touch Console MRC1010‑TN)
ViewSonic TeamJoin™ TRS10 With Display Bundle – Model CDE6530‑MTR (65″ 4K Display, Compute Engine MPC310‑W31‑TU & Touch Console MRC1010‑TN) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
ViewSonic TeamJoin™ TRS10 With Display Bundle – Model CDE6530‑MTR (...
Product Overview
The ViewSonic TeamJoin TRS10 CDE6530-MTR is a Microsoft Teams Rooms certified all-in-one conference room bundle built for small to medium meeting spaces. It pairs a commercial-grade 65-inch 4K UHD display with an Intel 12th Gen compute engine and a 10.1-inch touch scheduling console, delivering a complete, plug-and-play Teams Rooms deployment. IT teams can provision and power on a fully operational MTR room without additional hardware or complex integration work.
Bundle Components
- CDE6530 — 65-inch, 4K UHD (3840×2160), ADS panel, 450 nits, 24/7 rated commercial display
- MPC310-W31-TU — Intel 12th Gen Core i3-1220P compute engine, Windows 11 IoT Enterprise, TPM 2.0, Wi-Fi 6, Bluetooth 5.2
- MRC1010-TN — 10.1-inch Full HD touch scheduling console, PoE powered, HDMI BYOD ingest, human presence auto-wake
Product Description
The CDE6530-MTR bundle ships pre-configured for Microsoft Teams Rooms on Windows 11 IoT Enterprise, so deployment requires no custom imaging or driver setup. The CDE6530 display features an ADS-type LCD panel with direct-LED backlight, 450 nits of brightness, and a commercial-grade 24/7 operation rating—engineered for continuous conference room use. The MPC310-W31-TU compute engine runs the certified MTR software stack with Intel Threat Detection and TPM 2.0 hardware security built in. The MRC1010-TN touch console handles room scheduling, one-touch meeting join, and BYOD content sharing via its integrated HDMI ingest port, and it activates the system automatically when it detects human presence. This bundle is well-suited for small to medium conference rooms, executive offices, and hybrid collaboration spaces where a proven, certified Teams Rooms solution is required without extensive AV integration overhead.
Key Features
- Microsoft Teams Rooms Certified — Full MTR certification ensures native Teams experience, license-ready out of the box.
- 65-inch 4K UHD ADS Display — 3840×2160 resolution, 450 nits brightness, 178°/178° viewing angles, anti-glare coating.
- Intel 12th Gen Core i3-1220P — 10-core processor with Intel UHD Graphics; 8GB DDR4, Wi-Fi 6, Bluetooth 5.2.
- TPM 2.0 Security — Hardware-level authentication, Intel Threat Detection Technology, Smart App Control.
- 10.1-inch Touch Console — Full HD scheduling display with BYOD HDMI ingest and human presence sensor for auto-wake.
- 24/7 Commercial Rated — 50,000-hour backlight life; landscape and portrait orientation supported.
- Single-Vendor Certified Stack — All components sourced and certified together, reducing compatibility risk for IT.
Typical Applications
- Small to medium corporate conference rooms
- Hybrid meeting spaces and huddle rooms
- Executive boardrooms requiring Teams Rooms certification
- Government and education meeting rooms
- Corporate AV rollouts requiring standardized room kits
System Specifications
| Display Size | 65 inches |
| Resolution | 3840 × 2160 (4K UHD) |
| Brightness | 450 nits (typical) |
| Contrast Ratio | 1200:1 typical / 5000:1 dynamic |
| Panel Type | ADS with Direct-LED backlight |
| Response Time | 8 ms |
| Viewing Angles | 178° H / 178° V |
| Backlight Life | 50,000 hours |
| Operation Rating | 24/7 |
| Orientation | Landscape and Portrait |
| Compute Engine | MPC310-W31-TU — Intel Core i3-1220P, 12th Gen |
| Memory | 8GB DDR4 (Dual Channel) |
| Operating System | Windows 11 IoT Enterprise (MTR pre-installed) |
| Security | TPM 2.0, Intel Threat Detection, Smart App Control |
| Connectivity | HDMI Out, USB-C (PD + data), USB 3.0, RJ45, Wi-Fi 6, Bluetooth 5.2 |
| Touch Console | MRC1010-TN — 10.1" Full HD, 10-point touch, HDMI BYOD ingest |
| Certification | Microsoft Teams Rooms Certified |
| Warranty | 3-year limited |
Frequently Asked Questions
Q: Does this bundle require a Microsoft Teams Rooms license?
A: Yes. A Microsoft Teams Rooms license (Standard or Premium) is required to activate the MTR software. The hardware ships pre-installed with Windows 11 IoT Enterprise and the MTR application, but a valid Microsoft 365 or Teams Rooms license must be assigned to the room account before use.
Q: What room size is the CDE6530-MTR designed for?
A: The 65-inch display is optimally suited for small to medium conference rooms, typically seating 4–10 people, where viewing distances range from 6 to 16 feet.
Q: How long does initial setup take for an IT administrator?
A: With Microsoft Teams Rooms pre-installed and TPM 2.0 provisioning, most IT admins complete room setup in under 30 minutes—mounting, cabling, account sign-in, and policy push via Intune or manual configuration.
Q: What is the warranty coverage for this bundle?
A: All components carry a 3-year limited warranty from ViewSonic. Contact Creation Networks for warranty claims and support services.
Q: Is this bundle compatible with third-party cameras and audio devices?
A: Yes. The MPC310-W31-TU compute engine supports USB-connected cameras, speakerphones, and other Microsoft Teams Rooms certified peripherals. The bundle does not include a camera or audio device—add a certified USB camera/speakerphone or upgrade to the MTRC bundle which includes the UMB202 4K video bar.
