ViewSonic CDE105UW-MTRC Microsoft Teams Rooms Bundle – 105" 5K 21:9 Ultrawide Interactive Display (CDE105UW), Mini-PC (MPC310-W31-TU), 10.1" Touch Console (MRC1010-TN), 4K Video Bar (UMB202) with Intel 12th Gen, TPM 2.0, Auto-Framing
ViewSonic CDE105UW-MTRC Microsoft Teams Rooms Bundle – 105" 5K 21:9 Ultrawide Interactive Display (CDE105UW), Mini-PC (MPC310-W31-TU), 10.1" Touch Console (MRC1010-TN), 4K Video Bar (UMB202) with Intel 12th Gen, TPM 2.0, Auto-Framing is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
ViewSonic CDE105UW-MTRC Microsoft Teams Rooms Bundle – 105" 5K...
Product Overview
The ViewSonic CDE105UW-MTRC is the definitive large-format Microsoft Teams Rooms bundle, combining the 105-inch 5K (5120×2160) 21:9 ultrawide interactive display with the MPC310-W31-TU Intel 12th Gen compute engine, MRC1010-TN touch console, and UMB202 4K video bar. This complete four-component MTRC bundle delivers everything needed for an immersive, high-fidelity Teams Rooms deployment in executive boardrooms and large conference facilities—no additional hardware required beyond a Teams license and network connection.
Bundle Components
- CDE105UW — 105-inch, 5K (5120×2160), 21:9 ultrawide interactive display, multi-touch, 24/7 rated
- MPC310-W31-TU — Intel 12th Gen Core i3-1220P compute engine, Windows 11 IoT Enterprise, TPM 2.0, Wi-Fi 6, Bluetooth 5.2
- MRC1010-TN — 10.1-inch Full HD touch scheduling console, HDMI BYOD ingest, human presence auto-wake
- UMB202 — 4K video bar, 120° FOV Sony sensor, AI auto-framing, 5× digital zoom, 6-mic beamforming array, 8W+3W speakers
Product Description
The CDE105UW-MTRC pairs the expansive 5K ultrawide canvas of the CDE105UW with the premium AV capabilities of the UMB202 video bar to deliver the highest-caliber Teams Rooms experience available in the ViewSonic portfolio. The 105-inch 21:9 display format enables native side-by-side collaboration layouts—Teams call participants alongside a shared presentation, or dual full-document views—all at 5K resolution with multi-touch interactivity. The UMB202 video bar provides 4K video capture via Sony sensor with AI auto-framing, 5× ePTZ zoom, and Direction-of-Arrival voice tracking across a 6-mic beamforming array—ensuring every participant is clearly captured and clearly heard. The MPC310-W31-TU compute engine runs Microsoft Teams Rooms on Windows 11 IoT Enterprise with Intel 12th Gen Core i3-1220P processing (10 cores, 4.4GHz turbo), 8GB DDR4, and full TPM 2.0 hardware security. The MRC1010-TN touch console handles scheduling, one-touch join, BYOD HDMI ingest, and human presence auto-wake. Integrated cable management supports clean, professional installation. This is the choice for organizations that demand the most immersive and capable Teams Rooms deployment available.
Key Features
- 105-inch 5K 21:9 Ultrawide Multi-Touch Display — 5120×2160, immersive side-by-side collaboration at scale.
- Complete MTRC Certification — All four components certified together—single vendor, single warranty, complete solution.
- UMB202 4K Video Bar — Sony sensor, 120° FOV, AI auto-framing, 5× ePTZ zoom, DOA mic array, 8W+3W speakers.
- Intel 12th Gen Core + TPM 2.0 — Enterprise performance, hardware security, Wi-Fi 6, Bluetooth 5.2.
- Pre-installed Teams Rooms on Windows 11 IoT — Zero setup complexity; provision and deploy immediately.
- BYOD HDMI Ingest — Guest presentations via HDMI on the touch console with no software or adapters.
- Human Presence Auto-Wake — Automatic system activation on room entry for energy efficiency.
Typical Applications
- Flagship executive boardrooms
- Large conference rooms requiring premium AV and display
- Enterprise headquarters showcase collaboration spaces
- High-profile government and institutional meeting rooms
- Training centers with complex multi-source content needs
System Specifications
| Display Size | 105 inches (104.6" viewable) |
| Resolution | 5K (5120 × 2160), 21:9 aspect ratio |
| Touch Technology | Multi-touch interactive |
| Compute Engine | MPC310-W31-TU — Intel Core i3-1220P (10 cores, up to 4.4GHz) |
| Memory | 8GB DDR4 Dual Channel |
| Operating System | Windows 11 IoT Enterprise (MTR pre-installed) |
| Security | TPM 2.0, Intel Threat Detection, Smart App Control |
| Connectivity | HDMI Out, USB-C (PD+data), USB 3.0, RJ45, Wi-Fi 6, BT 5.2 |
| Touch Console | MRC1010-TN — 10.1" FHD, 10-pt touch, HDMI BYOD ingest |
| Video Bar Camera | UMB202 — 4K UHD, Sony sensor, 120° FOV, 5× zoom, ePTZ, auto-framing |
| Microphone | 6-element array, DOA tracking (UMB202) |
| Speakers | 8W + 3W front-facing (UMB202) |
| Certification | Microsoft Teams Rooms Certified |
| Warranty | 3-year limited |
Frequently Asked Questions
Q: Is a Teams Rooms license required?
A: Yes. A Microsoft Teams Rooms Standard or Premium license must be assigned to the room account before use.
Q: What makes the 5K 21:9 format better for collaboration?
A: The 21:9 format provides substantially more horizontal real estate than 16:9 displays, allowing true side-by-side layout—Teams participants on one half, shared content on the other—without compression or overlap. Multi-touch enables interactive annotation and whiteboarding at full resolution.
Q: How does the UMB202 handle a large room with many participants?
A: The UMB202’s AI auto-framing dynamically adjusts to keep all visible participants framed, while its 6-mic DOA beamforming array tracks the active speaker and reduces ambient noise across the room.
Q: What warranty is included?
A: All four components carry a 3-year limited ViewSonic warranty. Creation Networks provides support coordination.
Q: How does this compare to the CDE105UW-MTR bundle?
A: The MTRC bundle adds the UMB202 4K video bar (camera + microphone array + speakers). The MTR bundle requires separately sourced camera and audio peripherals. Choose MTRC for a complete, single-vendor certified solution.
