Vaddio ZoomSHOT 30 QUSB – 30x HD PTZ IP Camera System

Product Overview

The Vaddio ZoomSHOT 30 QUSB (part number 999-6930-100) is a professional HD point-of-view camera system purpose-built for fixed-installation AV environments. Delivering 30x optical zoom and full 1080p60 resolution, this Vaddio USB PTZ camera integrates directly with PC-based conferencing platforms as a plug-and-play UVC/UAC device over USB 2.0, while simultaneously offering HDMI, component (YPbPr), and IP streaming outputs for maximum deployment flexibility. The QUSB system ships as a complete package with a thin-profile wall mount and IR remote, making it a practical choice for AV integrators and facilities teams who need a proven, no-compromise camera solution.

Product Description

The Vaddio ZoomSHOT 30 QUSB is centered on a 1/2.8" Sony Exmor CMOS sensor rated at 1.3 megapixels, combining high-speed readout with low-noise performance — a sensor architecture well-regarded in professional videoconferencing cameras. The 30x optical zoom lens opens at a 63° horizontal field of view, wide enough to frame a full conference table or lecture stage, and the zoom reach handles IMAG applications in larger venues where subject-to-camera distances are significant.

Video outputs cover the full range of professional AV requirements: USB 2.0 with HD UVC and UAC compliance for direct connection to any Windows, macOS, or Linux host without drivers; HDMI for direct display or switching; component HD (YPbPr) for legacy signal chains; and IP streaming via RTSP and HLS using H.264 encoding for network distribution and recording workflows. An embedded web server provides browser-based control and configuration without additional software, and the system supports Vaddio's IP-based control protocol for integration with third-party control systems.

Power, video, and control are carried over two Cat-5e/6 cables to a distance of up to 150 feet from the host, keeping camera-side cabling minimal. Manual pan and tilt with Vaddio's EZ Set tensioning system allow precise repositioning and secure locking without tools. The camera ships with a thin-profile wall mount (black) with installation hardware and an IR Shot Commander remote for standalone operation. Procurement teams and AV designers can source this system at Creation Networks with pricing currently below MSRP — view current pricing and availability at creationnetworks.net.

Key Features

• 30x Optical Zoom — Covers intimate conference rooms through large-venue IMAG applications without sacrificing image quality at reach.
• 1080p60/50 Resolution — Full HD output at up to 60 frames per second for smooth, broadcast-quality video in high-motion scenarios.
• 1/2.8" Sony Exmor CMOS Sensor — Low-noise, high-speed image capture maintains clean video in challenging lighting conditions common in corporate and institutional spaces.
• 63° Horizontal Field of View — Wide starting angle allows flexible room coverage without repositioning the camera between participants.
• USB 2.0 UVC/UAC Output — Plug-and-play compatibility with Zoom, Microsoft Teams, Cisco Webex, and other UC platforms; no drivers required.
• Multi-Output Signal Architecture — Simultaneous HDMI, YPbPr component, USB, and IP streaming (RTSP/HLS H.264) outputs support complex signal distribution and recording requirements.
• Cat-5 Extension up to 150 ft — Power, video, and control over two Cat-5e/6 runs reduce camera-location wiring to a minimum and simplify installation in retrofit environments.
• Embedded Web Server — Browser-based control and configuration accessible from any networked device without additional software or client installation.
• Manual Pan/Tilt with EZ Set Tensioning — Secure, tool-free repositioning with adjustable tension for precise scene composition and stable lockdown.
• Complete System Package — Includes thin-profile wall mount, mounting hardware, installation manual, and Vaddio IR Shot Commander remote.

Typical Applications

• Corporate conference rooms and huddle spaces (UC-integrated or standalone)
• Houses of worship — live event capture and IMAG systems
• Distance learning classrooms and lecture capture installations
• Courtrooms and government meeting chambers
• Broadcast and live production environments requiring IP streaming
• Medical and telehealth consultation rooms
• Higher education lecture halls and seminar rooms
• Pro AV system integration projects requiring multi-output camera sources

Technical Specifications

Frequently Asked Questions

Q: Is the ZoomSHOT 30 QUSB compatible with Zoom, Microsoft Teams, and Cisco Webex?
A: Yes. The camera presents as a standard UVC (USB Video Class) device over USB 2.0, making it natively compatible with Zoom, Microsoft Teams, Cisco Webex, and any other platform that supports UVC-compliant cameras on Windows, macOS, and Linux — no drivers required.

Q: What cable infrastructure does this system require at the camera location?
A: The QUSB system carries power, video, and control over two Cat-5e or Cat-6 cables. The camera itself does not require a local power connection, which simplifies installations where AC power at the camera mount point is not available.

Q: Can the ZoomSHOT 30 QUSB stream video over the network simultaneously with USB output?
A: Yes. The system supports simultaneous outputs including USB 2.0, HDMI, YPbPr component, and IP streaming (RTSP and HLS with H.264 encoding), allowing concurrent local and network distribution without signal switching.

Q: How is the camera controlled without a dedicated controller?
A: The camera includes an embedded web server accessible from any browser on the network for configuration and control. The included Vaddio IR Shot Commander remote also provides direct IR control for scene and zoom adjustments. The camera additionally supports Vaddio's IP control protocol for integration with Crestron, AMX, Extron, and other third-party control systems.

Q: What is the maximum Cat-5 extension distance supported?
A: The ZoomSHOT 30 QUSB supports cable runs of up to 150 feet (approximately 46 meters) over two Cat-5e or Cat-6 cables, covering most standard conference room and classroom installation scenarios.

Q: Is the ZoomSHOT 30 QUSB appropriate for large-venue or IMAG applications?
A: Yes. The 30x optical zoom with a 63° wide-angle starting position gives operators the reach needed for IMAG systems in houses of worship, auditoriums, and event spaces where the camera may be positioned at a significant distance from the subject.

Q: Does the system include a wall mount?
A: Yes. The package includes a thin-profile wall mount in black with mounting hardware and installation documentation, along with a Vaddio IR Shot Commander remote. No separate mount purchase is required for standard wall installations.

Q: Where can I purchase the Vaddio ZoomSHOT 30 QUSB at the best price?
A: Creation Networks currently offers the 999-6930-100 below MSRP. Contact our team for volume pricing, project quotes, or integration support.
