Vaddio QuickCAT Mount with OneLINK HDMI for Vaddio, Sony, Panasonic - 999-82110-000

Product Overview

The Vaddio 999-82110-000 QuickCAT Mount with OneLINK HDMI is a ceiling mounting solution that integrates an OneLINK HDMI AV interface directly into the camera enclosure for clean, low-profile installations. Designed for invertible professional PTZ cameras from Vaddio, Sony, and Panasonic, it extends power, video, and control over a single Cat-5e or Cat-6 cable from the AV rack to the camera position — providing HDMI video output at the rack. Camera height is adjustable from 0 to 12 inches (0 to 305mm) below the ceiling tile. For installations requiring USB 3.0 soft-client conferencing output, see the OneLINK Bridge version (999-82210-000). For Cisco Precision 60/HD cameras, see 999-82120-000.

Product Description

The QuickCAT Mount with OneLINK HDMI combines a suspended ceiling camera mount and a Vaddio OneLINK HDMI interface into a single enclosure. This eliminates the need for a separate rack-mounted interface box at camera locations, simplifies cable routing, and provides a professional finished appearance for conference rooms, boardrooms, and public spaces.

The integrated OneLINK HDMI interface extends HDMI video, power, and control from the camera to the AV rack over a single Cat-5e or Cat-6 cable run — Cat-5e supports up to 230 ft (70m) and Cat-6 supports up to 328 ft (100m). The HDMI output at the rack connects to a display, codec, recording system, or distribution equipment. Height adjustment from 0 to 12 inches allows the installer to position the camera at the optimal angle, and the enclosure provides a finished look consistent with architectural ceiling tile grids.

Key Features

• Integrated OneLINK HDMI Interface - Combines ceiling mount and OneLINK HDMI in one enclosure, eliminating a separate rack-mounted interface box at the camera position.
• Compatible with Vaddio, Sony, and Panasonic PTZ Cameras - Supports most invertible professional PTZ cameras from these manufacturers.
• 0 to 12" Height Adjustment - Adjustable from 0 to 12 inches (305mm) below ceiling for optimal room coverage.
• Single-Cable HDBaseT Connectivity - HDMI video, power, and control over Cat-5e up to 230 ft (70m) or Cat-6 up to 328 ft (100m).
• HDMI Output at Rack - Connects to display, codec, recording, or distribution equipment via HDMI.
• Clean Ceiling Aesthetics - Finished enclosure for professional appearance in boardrooms and conference rooms.

Typical Applications

• Corporate boardrooms with suspended tile ceilings and HDMI display or codec connections
• Conference rooms with Vaddio, Sony, or Panasonic PTZ cameras requiring a single-cable ceiling mount
• Government and institutional meeting rooms with HDMI-based AV distribution
• Hospitality and event spaces with professional PTZ ceiling installations

Technical Specifications

Frequently Asked Questions

What is the difference between 999-82110-000 and 999-82210-000?
The 999-82110-000 uses OneLINK HDMI and provides an HDMI output at the rack. The 999-82210-000 uses OneLINK Bridge and provides simultaneous HDMI, USB 3.0, and HD-SDI outputs — enabling direct soft-client conferencing via USB 3.0. Choose the 82210-000 for rooms needing USB soft-client output (Zoom, Teams, Webex).

Which cameras are compatible?
Most invertible professional PTZ cameras from Vaddio, Sony, and Panasonic. Contact Creation Networks to confirm compatibility with your specific camera.

What is the maximum cable run?
Cat-5e up to 230 ft (70m); Cat-6 up to 328 ft (100m).
