Vaddio DocCAM 4K HDBT Document Camera with OneLINK Bridge — 999-99680-300
The DocCAM 4K HDBT with OneLINK Bridge pairs Vaddio's 4K ceiling-mounted document camera with the OneLINK Bridge receiver for single-cable installation. Power, video, and control travel over one Cat-5e or Cat-6 cable up to 328 ft, and the Bridge surfaces simultaneous HDMI, USB 3.0, IP streaming, and 3G-SDI outputs at the AV rack — plus a configurable audio matrix with AEC.
Description
The DocCAM 4K HDBT delivers 4K UHD imaging at up to 2160p/30 from a ceiling-mounted position using 30x optical zoom and a 70.2° horizontal field of view — capturing fine printed detail on documents, whiteboards, lab specimens, or architectural drawings. A low-power laser pointer assists in centering the camera frame before the lesson begins.
The included OneLINK Bridge extends power and video over a single Cat-5e cable up to 230 ft (70 m) or Cat-6 up to 328 ft (100 m), and simultaneously surfaces HDMI, USB 3.0 (up to 1080p/60 uncompressed), IP H.264 streaming, and 3G-SDI at the rack. The configurable audio matrix with AEC handles room audio bridging for direct Zoom, Teams, or Webex soft-client integration. Vaddio's web-based management interface provides remote control and administration from anywhere on the network.
Key Features
- 4K UHD ceiling-mounted document camera — up to 2160p/30 via 30x optical zoom
- 70.2° HFOV; laser pointer for frame centering
- Single-cable HDBaseT: Cat-5e to 230 ft or Cat-6 to 328 ft
- Simultaneous HDMI, USB 3.0, IP H.264 streaming, and 3G-SDI outputs
- Configurable audio matrix with AEC for soft-client conferencing
- Web-based management and remote control
- Compatible with Zoom, Teams, Webex via USB 3.0 UVC output
Typical Applications
Higher education classrooms, medical and nursing schools, technical training rooms, law school courtrooms, culinary schools, art studios, and any teaching environment where high-detail overhead imaging of documents, specimens, or objects must be captured and shared with remote participants.
Technical Specifications
| Model Number | 999-99680-300 |
| Max Resolution | 2160p/30 (4K UHD) |
| Optical Zoom | 30x |
| Horizontal FOV | 70.2° |
| Extension | OneLINK Bridge (HDBaseT) |
| Max Distance | 230 ft / 70 m (Cat-5e) · 328 ft / 100 m (Cat-6) |
| Video Outputs | HDMI, USB 3.0 (up to 1080p/60), IP H.264, 3G-SDI |
| Audio | Configurable matrix with AEC |
| Laser Pointer | Low-power Class 1 laser (IEC 60825-1:2014) |
