tvONE 1T-CT-653 – HDMI v1.4 HDBaseT Transmitter over Cat.5e/6
Product Overview
The tvONE 1T-CT-653 is an HDBaseT transmitter that extends HDMI v1.4 signals up to 100 meters (325 feet) over a single Cat.5e or Cat.6 cable when paired with the 1T-CT-654A receiver. Using HDBaseT 5Play technology, the system carries uncompressed 1080p/60Hz video, lossless audio, bidirectional IR, bidirectional RS-232, and Ethernet over the same cable run. Support for 4K UHD at 30Hz and HD 3D formats makes it suitable for both current and emerging display technologies. Power over HDBaseT (PoH) allows the receiver to draw power from the transmitter, eliminating the need for a local power source at the remote end.
Product Description
The 1T-CT-653 transmitter is the source-end unit in the tvONE HDBaseT 5Play extension system. It accepts an HDMI v1.4 input and encodes it for transmission over standard structured Cat.5e or Cat.6 cabling via a single RJ45 connection. The system achieves 100 meter (325 foot) runs for uncompressed 1080p/60Hz at 36-bit color depth, significantly extending HDMI beyond its native cable distance limitations. HDMI v1.4 features are fully supported, including 4K UHD at 30Hz, full HD 3D formats, and PC resolutions up to WUXGA. DVI sources can also be connected using HDMI-to-DVI adapters. Lossless audio formats including LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio are carried transparently. Bidirectional IR allows remote controls at the display end to operate source equipment, and bidirectional RS-232 enables control system integration across the cable run. Ethernet pass-through over the same cable supports network-connected displays or devices at the remote location. Power over HDBaseT (PoH) means the paired 1T-CT-654A receiver can be powered entirely from the transmitter end, reducing installation complexity when local power is unavailable. The 1T-CT-653 is also compatible with CORIOmax HDBaseT output modules, extending its application into tvONE matrix switching systems.
Key Features
- 100m / 325ft HDMI Extension — Transmits uncompressed HDMI v1.4 signals up to 100 meters over Cat.5e or Cat.6.
- HDBaseT 5Play Technology — Carries video, audio, IR, RS-232, and Ethernet over a single Cat.5e/6 cable.
- HDMI v1.4 Full Feature Support — Supports 4K UHD at 30Hz, 1080p/60Hz at 36-bit, 3D formats, and WUXGA PC resolutions.
- Power over HDBaseT (PoH) — Powers the 1T-CT-654A receiver from the transmitter end, eliminating remote power requirements.
- Lossless Audio Pass-Through — Carries LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio.
- Bidirectional IR — Passes infrared remote control signals in both directions for source control at the display location.
- Bidirectional RS-232 — Supports serial control pass-through for control system integration at both ends.
- Ethernet Pass-Through — Extends a network connection to the display location over the same cable.
- CORIOmax Compatibility — Compatible with tvONE CORIOmax HDBaseT output modules for matrix system integration.
- HDCP 1.1 and CEC Bypass — Handles protected content and passes CEC display control signals.
Typical Applications
- Conference rooms extending HDMI from a credenza AV rack to ceiling-mounted projectors or wall displays
- Lecture halls running HDMI from a podium source to displays at the back of the room
- Hotel meeting rooms with HDMI sources at the front-of-room rack and displays on far walls
- Boardrooms requiring control signal pass-through for RS-232 display control over the same cable
- Retail digital signage where HDMI player is centralized and displays are distributed throughout the space
- Integration with tvONE CORIOmax matrix systems via compatible HDBaseT output modules
Technical Specifications
| Specification | Value |
|---|---|
| Model | 1T-CT-653 |
| Paired Receiver | 1T-CT-654A (sold separately) |
| HDMI Standard | HDMI v1.4 / HDCP 1.1 / DVI 1.0 |
| HDBaseT Technology | HDBaseT 5Play |
| Maximum Distance | 100 m / 325 ft |
| Cable Type | Cat.5e or Cat.6 (RJ45) |
| Max Video Resolution | 1080p @ 60Hz / 36-bit; 4K UHD @ 30Hz |
| PC Resolution | Up to WUXGA (1920x1200) |
| 3D Support | Yes |
| Audio Formats | LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio |
| Control Pass-Through | Bidirectional IR, Bidirectional RS-232, Ethernet |
| Power over HDBaseT (PoH) | Yes (powers receiver) |
| CEC Bypass | Yes |
Frequently Asked Questions
What receiver pairs with the 1T-CT-653?
The 1T-CT-653 is designed to work with the tvONE 1T-CT-654A receiver, sold separately. The two units form a complete HDBaseT extension system.
How far can it extend HDMI?
The system extends uncompressed HDMI up to 100 meters (325 feet) over a single Cat.5e or Cat.6 cable.
Does it require a power supply at the remote display end?
Not necessarily. Power over HDBaseT (PoH) allows the 1T-CT-654A receiver to draw power from the transmitter end, so a local power supply at the display location is not required.
Can I pass RS-232 control signals through the cable?
Yes. Bidirectional RS-232 is supported, allowing control systems at either end to communicate with devices at the other end over the same Cat.5e/6 cable.
Is the 1T-CT-653 compatible with tvONE CORIOmax systems?
Yes. The unit is compatible with CORIOmax HDBaseT output modules, allowing it to serve as an extension transmitter in a tvONE matrix switching installation.
Does it support 4K content?
Yes. The system supports 4K UHD at 24Hz and 30Hz. For 4K at 60Hz over long distances, a different HDBaseT solution would be required.
Can a DVI source be connected?
Yes. A DVI source can be connected using an HDMI-to-DVI cable adapter. Audio is not carried over DVI connections.
