tvONE C7-PRO-1200 CALICO PRO – Compact 1RU 4K60 Video Processor

Product Overview

The tvONE C7-PRO-1200 CALICO PRO is a 1RU, 10-bit video processor engineered for LED video wall control and large-format display applications. With a fixed I/O configuration of six 4K60 inputs and two 4K60 outputs, the C7-PRO-1200 delivers pixel-accurate performance across up to 16.5 million pixels from a single, compact chassis. Designed for commercial AV integrators specifying a fixed-configuration 4K video wall processor, the CALICO PRO 1RU offers a space-efficient alternative to modular frame-based systems without sacrificing output quality or reliability.

Product Description

The C7-PRO-1200 is the compact 1RU member of the CALICO PRO family, providing the same 10-bit CORIO video processing technology found in larger tvONE processors in a streamlined fixed-I/O form factor. Six 4K60 inputs accommodate a wide range of sources including computers, media servers, and signal extender outputs, while two independent 4K60 outputs can drive LED processors, display walls, or downstream distribution equipment simultaneously. The built-in media store supports background images and source labels, enabling on-the-fly customization of canvas layouts without external playback hardware.

The CALICO PRO C7-PRO-1200 supports hundreds of low-latency 4K video windows across its dual outputs, with 24/7 continuous operation reliability suited to permanent installation environments such as control rooms, broadcast studios, and corporate video walls. Its 10-bit processing pipeline preserves color depth and gradient accuracy across all connected sources, important for high-end LED displays where banding artifacts are visible. The 1RU form factor integrates directly into standard 19-inch equipment racks, conserving rack space in tight installations. The processor is controlled via CORIOgrapher software, the same interface used across the broader tvONE CORIO product line, reducing training overhead for integrators already familiar with the platform. Control system integration is supported via IP and serial interfaces, with third-party control modules available for common AV control processors. The C7-PRO-1200 ships as a complete fixed-I/O unit — no module selection or configuration is required, making ordering and deployment straightforward for fixed-specification projects.

Key Features

• 6x 4K60 Inputs — Six fixed 4K60 inputs accept sources from computers, media servers, and signal extenders without requiring additional input modules.
• 2x 4K60 Outputs — Dual independent 4K60 outputs drive LED processors or displays simultaneously, supporting up to 16.5 million total pixels.
• 10-Bit Video Processing — CORIO 10-bit processing preserves color depth and eliminates gradient banding on high-quality LED displays.
• Built-In Media Store — Internal storage for background images and source labels enables canvas customization without external playback hardware.
• 1RU Fixed-I/O Design — Compact 1U chassis fits standard 19-inch racks and ships ready to deploy with no module configuration required.
• Low-Latency Windows — Supports hundreds of 4K video windows with minimal latency for live event and real-time control room applications.
• 24/7 Operation Rated — Engineered for continuous duty in permanent installation environments including broadcast, government, and corporate control rooms.
• CORIOgrapher Software Control — Uses the same control software as the broader CORIO platform, minimizing integrator training time.
• Third-Party Control Integration — IP and serial control interfaces support Crestron, AMX, Q-SYS, and other AV control systems.

Typical Applications

• LED video wall control rooms
• Corporate boardrooms and executive briefing centers
• Broadcast studio video walls
• Government operations centers
• Higher education auditoriums and presentation spaces
• Hospitality and retail large-format display installations
• Houses of worship with LED video wall systems
