TOA U-21S – Unbalanced Line Input Module with Remote Volume
Product Overview
The TOA U-21S is a plug-in unbalanced line input module for TOA 900 Series mixer-amplifiers, enabling integration of consumer line-level sources such as tuners, CD players, and media players into a professional distributed audio system. An optional external 10 kΩ linear-taper potentiometer provides remote volume control at the listening position.
Product Description
Designed for the TOA 900 Series modular platform, the U-21S slides directly into any open module slot without tools. Its unbalanced input accepts standard consumer or semi-pro signal levels, and the high 220 kΩ input impedance ensures minimal loading on source equipment. The built-in buffer amplifier delivers a stable output to the amplifier's summing bus, covering the full 20 Hz to 20 kHz audio band within ±1.5 dB. The module draws just 27 mA from the chassis 24 VDC supply, making it suitable for fully loaded chassis without power budget concerns.
Key Features
- Plug-In 900 Series Compatibility: Mounts directly in any TOA 900 Series amplifier chassis with no tools required.
- High Input Impedance: 220 kΩ input impedance minimizes loading on CD players, tuners, and media sources.
- Remote Volume Control: Accepts an external 10 kΩ linear potentiometer for wall-panel volume adjustment at a remote listening location.
- Wide Frequency Response: 20 Hz–20 kHz (±1.5 dB) ensures full-range audio reproduction across the PA system.
- Low Power Draw: Operates on 24 VDC at only 27 mA, preserving chassis headroom in fully loaded configurations.
- Compact Format: 35 × 78 × 88 mm profile fits the standard 900 Series module bay.
Technical Specifications
| Input Type | Unbalanced, screw terminals |
|---|---|
| Input Impedance | 220 kΩ |
| Frequency Response | 20 Hz–20 kHz (±1.5 dB) |
| Remote Volume Control | External 10 kΩ linear potentiometer |
| Power Supply | 24 VDC, 27 mA (from chassis) |
| Dimensions (W×H×D) | 35 × 78 × 88 mm |
| Compatible Platform | TOA 900 Series amplifiers |
