TOA M-01S – 900 Series Mic Input Module

Product Overview

The TOA M-01S microphone input module adds a balanced, low-impedance microphone channel to a 900 Series mixer/amplifier, making it a practical choice for paging and background music systems that need a clean voice input. This 900 Series plug-in module accepts dynamic or condenser microphones through a removable terminal block and supplies selectable phantom power for condenser elements. As a dedicated balanced microphone input module, it integrates into commercial PA racks alongside other TOA 900 Series modules. Gain and tone controls let an installer match the input to the room and the source.

Product Description

The M-01S installs into a 900 Series module slot on compatible TOA mixer/amplifiers and main frames, drawing its 24 V DC operating power directly from the host chassis. Its transformer-isolated 600 ohm input handles balanced, low-impedance microphones over typical commercial cable runs while rejecting common-mode noise. A switchable +22 V DC phantom supply powers condenser microphones, and high- and low-cut tone controls help tame room boom and sibilance. The adjustable gain range of 32 to 52 dB lets the module serve everything from close-talk paging microphones to ambient lectern mics. Connection is made through a removable 3-pole terminal block, which simplifies servicing and pre-wiring during installation. Because it follows the standard 900 Series module format, the M-01S can be combined with line input, telephone paging, and signal-processing modules in the same frame. This makes it well suited to distributed audio and paging deployments in schools, offices, and retail spaces. Installers gain a repeatable, rack-based way to add microphone inputs without dedicating a full mixer channel.

Key Features

• Balanced Microphone Input — A transformer-isolated 600 ohm input accepts balanced, low-impedance microphones for quiet, interference-resistant connections.
• Selectable Phantom Power — A +22 V DC phantom supply can be enabled or disabled so the module works with both condenser and dynamic microphones.
• High and Low Tone Controls — Independent 100 Hz and 10 kHz cut controls let installers shape voice clarity for the acoustics of each room.
• Adjustable Gain — A 32 to 52 dB gain range matches the module to a wide variety of microphone sensitivities and speaking levels.
• Removable Terminal Block — The 3-pole pluggable connector speeds installation, pre-wiring, and field service in busy equipment racks.
• 900 Series Compatibility — The standard module format installs in compatible TOA 900 Series mixer/amplifiers and main frames for flexible system design.
