TOA U-43S – AUX Input Module, Terminal Block
Product Overview
The TOA U-43S aux module provides an unbalanced line-matching input with voice-activated muting for the 900 Series modular platform. This 900 series aux module terminates on a screw-terminal connector, making it well suited to permanent installations where source wiring is landed directly in the rack. Like other U-43 modules, it ducks background music automatically when a priority announcement is made.
Product Description
The U-43S installs in a single 900 Series module slot and accepts an unbalanced line source through a terminal-block connector, the preferred termination for hard-wired permanent installs. Its line-matching input stage sets levels appropriately for the host mixer-amplifier, while the mute-send control output provides voice-activated muting so background music attenuates during paging. This combination supports automatic priority behavior in retail, hospitality, and commercial meeting spaces without additional control hardware. The screw-terminal connector lets integrators land field wiring cleanly and securely, which is an advantage during rack assembly and later service. Because the module shares the slot format used across the 900 Series, a single chassis can carry the exact mix of microphone, line, and aux inputs a project requires. The U-43S is a dependable choice for new distributed audio builds and for adding terminal-block sources to existing 900 Series systems.
Key Features
- Unbalanced Line-Matching Input — Sets source levels correctly for the host amplifier from an unbalanced line source.
- Terminal-Block Connector — Screw terminals let integrators land hard-wired field cabling cleanly for permanent installations.
- Voice-Activated Muting — A mute-send control output ducks background music automatically during priority announcements.
- 900 Series Slot Compatibility — Installs in any standard 900 Series module slot for flexible configuration.
- Install-Ready Design — Suits new builds and retrofits that rely on terminal-block source wiring.
Technical Specifications
| Module type | AUX module (900 Series) |
| Input | Unbalanced line-matching input |
| Connector | Screw terminal (terminal block) |
| Control | Mute-send (voice-activated muting) |
Specifications per the TOA U-43S datasheet.
