TOA Electronics AM/FM Tuner with Digital Display (1 RU, Black) - DT-940 CU

Overview

The TOA DT-940 CU is a rack-mount AM/FM tuner designed for commercial background music applications. It stores up to 20 AM and 20 FM station presets for instant one-touch recall, and its front-panel lockout prevents unauthorized changes — ideal for restaurants, retail environments, and multi-zone AV systems.

Description

Installed in an EIA 1U rack space, the DT-940 CU provides reliable AM/FM broadcast reception for permanent commercial AV installations. Frequency synthesized digital tuning ensures stable, drift-free operation, while the multi-function digital display makes station identification clear at a glance. Auto-scan mode automatically detects and stores available stations in memory. Both FM stereo and AM monaural reception are supported, and a stereo audio output connects directly to mixer amplifiers or zone processors. An FM wire antenna and AM loop antenna are included in the box.

Key Features

• 20 AM (monaural) and 20 FM preset memory stations — instant one-touch recall
• Automatic station scanning and manual tuning modes
• Auto-scan automatically stores available stations in memory
• Frequency synthesized digital tuning with multi-function digital display
• Stereo FM output; monaural AM output
• Front panel lockout prevents unauthorized operation
• FM wire antenna and AM loop antenna included
• 1U EIA rack-mount design; optional MB-15B rack bracket available

Typical Applications

• Restaurant and retail store background music systems
• Hotel lobby and common-area ambient audio
• Multi-zone paging and BGM distribution networks
• Conference centers and corporate AV installations
• Houses of worship and auditorium background music

Technical Specifications

FAQ

Can the DT-940 CU be integrated with a TOA mixer amplifier for zone distribution?
Yes. The DT-940's stereo audio output connects directly to any line-level input on a TOA mixer amplifier, such as the MA-725F or A-5006 series, enabling AM/FM to be one source in a multi-zone BGM system.

How does front panel lockout work?
When front panel lockout is enabled, station preset and tuning controls are disabled at the unit — only the connected control system or AM/FM source selection remains active. This prevents unauthorized station changes in public venues.

Does it support stereo output?
Yes, the DT-940 supports stereo FM output. AM broadcasts are monaural by nature.

What rack bracket is required?
The optional TOA MB-15B Rack Mounting Bracket is required for standard EIA rack installation. The unit does not ship with the bracket by default.
