TOA F-2852C 6.5" 2-Way Coaxial Ceiling Speaker - 60 W, 70 V / ...
Product Overview
The TOA F-2852C is a 6.5" two-way coaxial ceiling speaker built for commercial background music and paging installations. A bass-reflex enclosure extends low-frequency response while the coaxial driver arrangement aligns the 1" dome tweeter on the woofer axis for consistent horizontal and vertical dispersion. The F-2852C operates on 100 V, 70 V, and 25 V distributed audio lines as well as 8 Ω direct, covering the majority of commercial PA system configurations.
Product Description
With a 10" (250 mm) cutout requirement and a rear depth of only 7.9" (200 mm), the F-2852C fits standard plenum ceiling installations. Sensitivity is rated at 91 dB (1 W, 1 m) and power handling reaches 60 W on the 100 V tap. Selectable transformer taps allow output levels to be matched to zone coverage requirements without additional attenuators. Order the TOA F-2852C from Creation Networks.
Key Features
- 6.3" (16 cm) cone woofer with 1" (2.5 cm) dome tweeter in a coaxial arrangement
- 2-way bass-reflex enclosure for extended low-frequency response from 60 Hz
- 91 dB SPL sensitivity (1 W, 1 m)
- Selectable transformer taps on 100 V, 70 V, and 25 V lines plus 8 Ω direct
- 60 W maximum power handling (100 V / 70 V tap)
- Fits ceilings up to 1.46" (37 mm) thick; 10" (250 mm) cutout required
- Shallow rear depth of 7.9" (200 mm) for plenum-rated installations
Technical Specifications
| Specification | Value |
|---|---|
| Driver Configuration | 6.3" (16 cm) cone LF + 1" (2.5 cm) dome HF, coaxial |
| Enclosure Type | 2-way bass-reflex |
| Sensitivity | 91 dB SPL (1 W, 1 m) |
| Frequency Response | 60 Hz – 20 kHz (–10 dB); 45 Hz – 20 kHz (–20 dB) |
| Rated Power – 100 V / 70 V | 60 W, 30 W, 15 W, 3 W (selectable) |
| Direct Impedance | 8 Ω |
| Cutout Diameter | 10" (250 mm) |
| Outside Diameter | 11.1" (280 mm) |
| Mounting Depth | 7.9" (200 mm) |
| Max Ceiling Thickness | 1.46" (37 mm) |
| Weight | 11.24 lbs (5.1 kg) |
