Teris TS350-CINE Fluid Head

Product Overview

The Teris TS350-CINE is a heavy-duty 150mm cinema fluid head engineered for professional film and broadcast camera operators working with large-format cinema rigs. With a 40 kg payload rating, a drop-in quick release plate, and independent stepless pan and tilt drag systems, the TS350-CINE provides the control and reliability required for high-end narrative film, broadcast, and documentary production. Sold as a head-only unit, it pairs with any 150mm bowl-compatible tripod system and is a direct upgrade path for operators already running 150mm legs. This professional cinema fluid head is the top of the Teris range and is built to handle the most demanding camera configurations in the field.

Product Description

The TS350-CINE fluid head accepts payloads up to 40 kg (88 lb), making it suitable for fully dressed cinema cameras including large cinema primes, matte boxes, wireless follow focus systems, and on-board monitors. The 150mm bowl interface is the professional standard for heavy cinema and broadcast support, compatible with studio pedestals, high hats, and any 150mm tripod system. A drop-in quick release plate with both 1/4"-20 and 3/8"-16 camera screw options simplifies mounting cinema cameras with standard dovetail base plates or direct bolt-on configurations. The sliding plate design allows fore-aft balance adjustment before locking down, reducing the time needed to balance changing lens configurations. Independent pan and tilt drag controls let the camera operator tune each axis separately, allowing, for example, a stiffer pan for a static multi-camera setup and a looser tilt for following action. The counterbalance system adjusts to compensate for different camera build weights, maintaining neutral balance across the tilt range. At 7.15 kg head weight, the TS350-CINE is a substantial but manageable fluid head for a professional camera operator or assistant working on feature films, broadcast dramas, and live events.

Key Features

• 40 kg Payload Capacity — Handles fully dressed cinema camera rigs up to 88 lb, including cameras, lenses, and all accessories.
• 150mm Bowl Interface — Fits any standard 150mm tripod system or studio pedestal; compatible with Mitchell adapters and high hats.
• Drop-in Quick Release Plate — Fast camera attachment and release; supports 1/4"-20 and 3/8"-16 screws for broad camera compatibility.
• Sliding Balance Adjustment — Fore-aft plate adjustment enables balance correction when changing lenses or accessories without removing the camera.
• Stepless Pan and Tilt Drag — Independent, continuously adjustable drag on both axes for precise movement control matched to the shot.
• Counterbalance System — Adjustable counterbalance compensates for varying camera build weights across the tilt range.
• Aluminum Construction — Durable aluminum body provides long-term reliability in professional rental and owner-operator environments.
• Head-Only Purchase Option — Purchased separately from the tripod, making it ideal for operators upgrading from an existing 150mm leg system.

Typical Applications

• Film production (narrative, commercial, and music video)
• Broadcast studio and multi-camera production
• Documentary production
• ENG/field production with heavy broadcast lenses
• Live event production
• House of worship multi-camera installations

Technical Specifications

Frequently Asked Questions

Q: Does the TS350-CINE include tripod legs?
A: No. The TS350-CINE is sold as a fluid head only. It is compatible with any standard 150mm bowl tripod system, including the Teris TS350CF-CINE tripod legs.

Q: What is the maximum payload?
A: The TS350-CINE is rated for 40 kg (88 lb), which covers the heaviest cinema camera configurations in professional use.

Q: Can I use this head on a studio pedestal?
A: Yes. The 150mm bowl fits directly on compatible studio pedestals. Verify your pedestal's bowl size before purchasing.

Q: What camera screw sizes does the quick release plate support?
A: The drop-in quick release plate includes both 1/4"-20 and 3/8"-16 screw options to accommodate a wide range of cinema cameras and base plates.

Q: How does the sliding plate work?
A: The plate slides fore and aft to shift the camera's center of gravity relative to the tilt axis, allowing balance adjustment to compensate for lens changes without removing the camera from the head.

Q: Is the drag system stepless or does it have fixed positions?
A: The drag system is stepless on both pan and tilt axes, allowing infinitely variable drag adjustment rather than fixed detent positions.

Q: What is the weight of the head itself?
A: The TS350-CINE fluid head weighs 7.15 kg without camera or accessories.
