Teris TS300 Fluid Head

Product Overview

The Teris TS300 is a professional 100mm fluid head rated for 30 kg payloads, designed for broadcast, ENG, and documentary camera operators who need a reliable, high-capacity head to pair with their existing 100mm tripod system. With stepless drag on both pan and tilt axes, a 0–7 grade counterbalance system, and an aluminum construction, the TS300 delivers precise, repeatable camera movement for demanding production environments. Sold as a head-only unit, it suits operators upgrading from a lower-capacity head without replacing their current legs. The TS300 is a direct fit for professional broadcast cameras, compact cinema cameras, and heavy mirrorless configurations with accessories.

Product Description

The Teris TS300 fluid head offers a 30 kg payload in a 4.96 kg aluminum body, making it a capable and moderately portable choice for broadcast operators who need head-only solutions. The 100mm bowl fitting is the standard for mid-range professional tripod systems, and the TS300 is compatible with any 100mm tripod legs in a production inventory. The drag system offers 0–7 adjustment grades on both pan and tilt axes, providing a meaningful range from minimal resistance for smooth, flowing movements to firm drag for locked-off or slow pan shots. The counterbalance system also runs 0–7, allowing the head to be tuned for camera builds ranging from a lighter ENG body to a fully kitted broadcast camcorder with a large zoom lens. The tilt range of +90° to -75° covers the full range of practical shooting angles including high-angle overhead shots and low-angle ground-level coverage. For broadcast studio operators, documentary crews, and ENG teams who need a dependable 100mm fluid head with a solid payload rating and precise drag control, the TS300 is a well-specified choice.

Key Features

• 30 kg Payload Capacity — Handles professional ENG cameras, broadcast zoom lenses, and compact cinema rigs with accessories.
• 100mm Bowl Interface — Industry-standard fitting compatible with a wide range of professional tripod systems.
• 0–7 Grade Pan Drag — Seven-position drag adjustment on the pan axis for precise movement control across a range of shot types.
• 0–7 Grade Tilt Drag — Independent tilt drag adjustment matches tilt resistance to the camera weight and shot requirements.
• 0–7 Grade Counterbalance — Adjustable counterbalance accommodates different camera build weights and maintains neutral balance across the tilt range.
• +90° / -75° Tilt Range — Full tilt coverage for overhead and low-angle shots without requiring additional accessories.
• Aluminum Construction — Durable build suited to rental house inventory and daily professional use.
• Head-Only Purchase — Pairs with any existing 100mm bowl tripod system, making it an efficient upgrade option.

Typical Applications

• Broadcast studio production
• ENG/field production
• Documentary production
• Multi-camera production
• House of worship
• Live event production

Technical Specifications

Frequently Asked Questions

Q: Does the TS300 include tripod legs?
A: No. The TS300 is sold as a fluid head only. It is compatible with any 100mm bowl tripod system, including the Teris TS300CF carbon fiber legs.

Q: What is the maximum payload?
A: The TS300 is rated for 30 kg, covering professional ENG cameras, broadcast zoom lenses, and compact cinema rigs with accessories.

Q: How many drag adjustment positions are available?
A: The drag system offers 8 positions (0 through 7) on both pan and tilt axes, independently adjustable.

Q: What does the counterbalance range (0–7) mean?
A: The 0–7 counterbalance grades correspond to different levels of spring tension to counteract the weight of the camera and lens. Setting 0 provides no counterbalance for very light configurations; 7 provides maximum counterbalance for heavier builds.

Q: Is the TS300 compatible with the TS300CF-Q kit legs?
A: Yes. The TS300 fluid head is the same head included in the TS300CF-Q kit. Purchasing the head only is appropriate if you already have compatible 100mm carbon fiber or aluminum legs.

Q: What is the tilt range?
A: The TS300 tilts +90° forward and -75° back, providing coverage for overhead and low-angle shots.

Q: Is this head suitable for house of worship fixed-camera positions?
A: Yes. The TS300 is well suited for house of worship installations where a reliable 100mm fluid head with good drag control is needed for stationary or slowly panning camera positions.
