Teradek 10-2591-V Ranger Mk II 2500 12G-SDI/HDMI - Wireless TX V-Mount
Product Overview
The Teradek 10-2591-V Ranger Mk II 2500 12G-SDI/HDMI Wireless Transmitter (V-Mount) is the standalone TX unit from the Ranger MK II 2500 series, transmitting visually lossless 4K60 video up to 2,500 feet line of sight across 4.9–6.0 GHz. The integrated V-Mount battery plate enables camera-back or rig-mounted battery-powered deployment on broadcast and film productions. Compatible with Ranger MK II and Bolt 4K series receivers.
Product Description
The 10-2591-V accepts 12G-SDI and HDMI 2.0 inputs with a 12G-SDI loop output, transmitting 4K60 HDR video in 10-bit 4:2:2 with sub-1ms latency. The V-Mount plate powers the unit via standard professional batteries without DC cabling. AES-256 encryption with RSA-1024 key exchange secures the wireless link, and one transmitter feeds up to six receivers simultaneously. The Bolt Manager app connects via Bluetooth for spectrum analysis and remote configuration.
Key Features
- 2,500 ft TX Range — Mid-to-long-range transmitter for broadcast and film production.
- 4K60 10-bit 4:2:2 HDR — Visually lossless with Rec. 2020 HDR and sub-1ms latency.
- 12G-SDI and HDMI 2.0 Inputs — With 12G-SDI loop-through output.
- V-Mount Battery Plate — Integrated for battery-powered camera-back deployment.
- Multicast to 6 Receivers — One TX feeds up to six RX units simultaneously.
- AES-256 Encryption — RSA-1024 key pairing for end-to-end security.
Typical Applications
- Feature film camera-back transmitter
- Broadcast and live event production
- Government and large-venue video operations
Technical Specifications
| Specification | Value |
|---|---|
| Model | 10-2591-V |
| TX Range | Up to 2,500 ft line of sight |
| Video Latency | <1ms |
| Video Inputs | 1x 12G-SDI, 1x HDMI 2.0 |
| Loop Output | 1x 12G-SDI |
| Color Sampling | 10-bit 4:2:2, Rec. 2020 HDR |
| Operating Frequency | 4.9–6.0 GHz |
| Battery Mount | V-Mount |
| Encryption | AES-256, RSA-1024 |
Frequently Asked Questions
- What receivers are compatible with this transmitter?
- The 10-2591-V is compatible with Ranger MK II receivers and Bolt 4K series receivers over 5 GHz.
- How many receivers can this TX feed simultaneously?
- Up to six receivers can connect at the same time.
- What warranty applies?
- Teradek provides a standard limited warranty. Contact Creation Networks for support details.
