Teradek 10-2581-G Ranger Mk II 750 12G-SDI/HDMI - Wireless TX Gold-Mount
Teradek 10-2581-G Ranger Mk II 750 12G-SDI/HDMI - Wireless TX Gold-Mount is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Teradek 10-2581-G Ranger Mk II 750 12G-SDI/HDMI - Wireless TX Gold-...
Product Overview
The Teradek 10-2581-G Ranger Mk II 750 12G-SDI/HDMI Wireless Transmitter (Gold-Mount) is the standalone TX unit from the Ranger MK II 750 series, transmitting visually lossless 4K60 video up to 750 feet line of sight. The integrated Gold Mount battery plate enables camera-back or rig-mounted battery-powered deployment for film and broadcast productions. Pairs with any Ranger MK II or Bolt 4K series receiver.
Product Description
The 10-2581-G accepts 12G-SDI and HDMI 2.0 inputs with a 12G-SDI loop output, transmitting 4K60 HDR in 10-bit 4:2:2 across 4.9–6.0 GHz with less than 1ms latency. Gold Mount battery plate powers the unit via Anton/Bauer-compatible batteries. AES-256 encryption with RSA-1024 key exchange secures the link; one TX feeds up to six receivers simultaneously. Bolt Manager app connects via Bluetooth for spectrum analysis and configuration.
Key Features
- 750 ft TX Range — Short-to-mid-range 4K wireless transmitter for film and broadcast production.
- 4K60 10-bit 4:2:2 HDR — Visually lossless with Rec. 2020 HDR and sub-1ms latency.
- 12G-SDI and HDMI 2.0 Inputs — With 12G-SDI loop-through output.
- Gold Mount Battery Plate — Integrated for camera-back battery-powered operation.
- Multicast to 6 Receivers — Single TX feeds up to six RX units.
- AES-256 Encryption — RSA-1024 key exchange for wireless security.
Technical Specifications
| Specification | Value |
|---|---|
| Model | 10-2581-G |
| TX Range | Up to 750 ft line of sight |
| Video Inputs | 1x 12G-SDI, 1x HDMI 2.0 |
| Loop Output | 1x 12G-SDI |
| Operating Frequency | 4.9–6.0 GHz |
| Battery Mount | Gold Mount |
| Encryption | AES-256, RSA-1024 |
Frequently Asked Questions
- What receivers pair with this transmitter?
- Ranger MK II receivers and Bolt 4K series receivers over 5 GHz. Browse at creationnetworks.net.
- How many receivers can this TX feed simultaneously?
- Up to six.
- What warranty applies?
- Teradek standard limited warranty. Contact Creation Networks.
