Teradek 10-2556 Ranger Micro 5000 3G-SDI/HDMI - Wireless TX No Mount
Product Overview
The Teradek 10-2556 Ranger Micro 5000 3G-SDI/HDMI Wireless Transmitter (No Mount) is the standalone TX unit from the Ranger Micro 5000 series, transmitting wireless HD video up to 5,000 feet line of sight across 4.9–6.0 GHz. The no-mount configuration is optimized for DC-powered deployments in studio, vehicle, or fixed production environments where a battery plate is not required. Pairs with compatible Ranger Micro 5000 or Teradek receivers.
Product Description
The 10-2556 accepts 3G-SDI and HDMI inputs with a 3G-SDI loop output, transmitting wirelessly over 4.9–6.0 GHz with visually lossless compression and sub-1ms latency. Powers via DC input without a battery plate. AES-256 encryption with RSA-1024 key exchange secures the link. Bolt Manager app connects via Bluetooth for spectrum analysis and remote configuration. Compatible with Teradek Core cloud management.
Key Features
- 5,000 ft TX Range — Maximum-range Ranger Micro transmitter for long-distance HD production.
- 3G-SDI and HDMI Inputs — HD signal chain with 3G-SDI loop output.
- No Battery Mount — DC-powered for studio and vehicle-based production.
- 4.9–6.0 GHz Operation — Wide frequency band with auto/manual channel selection.
- AES-256 Encryption — RSA-1024 key exchange for wireless security.
- Bolt Manager App — Bluetooth spectrum analysis and remote configuration.
Technical Specifications
| Specification | Value |
|---|---|
| Model | 10-2556 |
| TX Range | Up to 5,000 ft line of sight |
| Inputs | 3G-SDI, HDMI |
| Loop Output | 3G-SDI |
| Operating Frequency | 4.9–6.0 GHz |
| Battery Mount | None (DC-powered) |
| Encryption | AES-256, RSA-1024 |
Frequently Asked Questions
- What receivers pair with the 10-2556?
- Compatible Ranger Micro 5000 receivers (10-2557-V or 10-2557-G). Browse at creationnetworks.net.
- For battery-powered operation, what should I order instead?
- See the Ranger Micro 5000 Gold Mount or V-Mount kit versions which include integrated battery plates.
- What warranty applies?
- Teradek standard limited warranty. Contact Creation Networks for support.
