ViewSonic TD2455 – 24-Inch 10-Point IR Touch Monitor
Product Overview
The ViewSonic TD2455 is a 24-inch (23.8" viewable) Full HD PCAP touch monitor built for commercial AV deployments that require both precise touch input and ergonomic flexibility. Its advanced dual-hinge stand accommodates seated and standing users alike, making it a strong fit for reception kiosks, corporate huddle rooms, and podium installations. The in-cell 10-point projected capacitive touch panel supports Windows, Linux, and ChromeOS natively, and a USB-C input with 60W power delivery reduces cable clutter for laptop-driven workflows.
Product Description
Designed for productive, touch-first workspaces, the ViewSonic TD2455 combines a SuperClear IPS panel with responsive in-cell PCAP touch technology. The three-sided ultra-thin bezel design maximizes visible screen area, while 178-degree horizontal and vertical viewing angles keep content accurate from off-axis positions. DisplayPort Multi-Stream Transport (MST) allows the TD2455 to daisy-chain to a second display over a single cable, a practical advantage in dual-monitor deployments. A USB 3.2 Type-C input carries video, audio, data, and up to 60W of charging power simultaneously. An included passive stylus pen attaches magnetically to the base of the stand for secure storage. The display is ENERGY STAR and EPEAT certified, and carries a three-year limited warranty with backlight coverage. Its dual-hinge stand tilts from 5 degrees to 60 degrees, supporting everything from upright desktop use to near-flat podium positioning. Two USB-A ports on the panel provide peripheral connectivity for keyboards, mice, or barcode scanners in kiosk configurations.
Key Features
- 24" IPS PCAP Touch Monitor — 23.8" viewable SuperClear IPS panel delivers consistent color at 178-degree horizontal and vertical viewing angles.
- 10-Point In-Cell Touch — Projected capacitive technology with Windows 7/8/10, Linux (Ubuntu 18.04/19.04), and ChromeOS support.
- Dual-Hinge Ergonomic Stand — Tilts 5° to 60°, accommodating both seated desktop and standing podium use cases.
- USB-C with 60W Power Delivery — USB 3.2 Type-C carries video, audio, data, and laptop charging over a single cable.
- DisplayPort MST Daisy-Chaining — Connect a second display via DisplayPort out without additional cabling to the host PC. (MacOS not supported.)
- Included Passive Stylus — Magnetically stores on the display stand base for quick access during annotation or check-in workflows.
- Dual Integrated Speakers — 2W × 2 speakers suitable for kiosk audio prompts and standard desktop use.
- VESA 100×100 Mount — Compatible with third-party arms and wall mounts for flexible installation.
- ENERGY STAR / EPEAT Certified — Meets commercial procurement sustainability requirements.
Typical Applications
- Conference room and boardroom interactive podium displays
- Corporate reception and check-in kiosk stations
- Training room interactive workstations
- Healthcare patient registration and intake terminals
- Government facility self-service kiosks
Technical Specifications
| Specification | Value |
|---|---|
| Screen Size | 24" (23.8" viewable) |
| Panel Type | IPS (SuperClear) |
| Resolution | 1920 × 1080 (Full HD) |
| Brightness | 250 cd/m² |
| Static Contrast Ratio | 1,000:1 |
| Dynamic Contrast Ratio | 50,000,000:1 |
| Response Time | 14ms (typical GTG), 6ms (GTG w/OD) |
| Viewing Angles | 178° horizontal, 178° vertical |
| Refresh Rate | 60Hz |
| Touch Technology | Projective Capacitive (PCAP), 10-point |
| Touch Compatibility | Windows 7/8/10, Linux Ubuntu 18.04/19.04, ChromeOS |
| Connectivity | HDMI 1.4, DisplayPort 1.2 in, DisplayPort out (MST), USB-C 3.2 (60W), 2× USB-A, 1× USB-B |
| VESA Mount | 100 × 100 mm |
| Tilt | 5° / 60° |
| Power Consumption (typical) | 19.6W |
| Dimensions (W×H×D) | 21.2" × 16.8" × 11.3" (with stand) |
| Weight | 14.2 lbs (with stand) |
| Speakers | 2W × 2 |
| Certifications | ENERGY STAR, EPEAT, cTUVus, FCC-B |
| Warranty | 3-year limited (parts, labor, backlight) |
Frequently Asked Questions
Q: Does the TD2455 work with macOS?
A: Touch input works natively on Windows, Linux, and ChromeOS. macOS users can enable touch via ViewSonic's vTouch driver, though iOS/iPadOS devices are not supported. DisplayPort MST daisy-chaining is not supported on macOS.
Q: Can the TD2455 be VESA-mounted?
A: Yes. The display is compatible with standard 100×100mm VESA mounts, making it suitable for wall mounts, pole mounts, and articulating arms.
Q: What is the maximum tilt angle?
A: The dual-hinge stand tilts from 5° (near upright) to 60° (near flat), supporting podium-style touch use at steep angles.
Q: Does the USB-C port deliver power to a connected laptop?
A: Yes. The USB 3.2 Type-C port delivers up to 60W of power to a connected device while simultaneously carrying video and audio signals.
Q: Is a stylus included?
A: Yes. A passive touch stylus is included and attaches magnetically to the base of the display stand.
Q: What inputs does the TD2455 support?
A: HDMI 1.4, DisplayPort 1.2 in, DisplayPort out (MST), and USB-C 3.2. A USB hub with 2× USB-A and 1× USB-B is also included.
Q: Can this display be used in a dual-monitor setup?
A: Yes. DisplayPort MST allows you to connect a second monitor via the DP out port from a single video source cable, on Windows systems.
