Tascam TA-1VP Vocal Processor

Availability: Call for Availability
Availability: Direct Ship
Tascam SKU: TA-1VP
No reviews
Price:
$499.00 $849.00

Description

The TA-1VP from TASCAM is a vocal processor utilizing Antares' technologies (AutoTune and Mic Modeler) to deliver everything needed for a polished, modern vocal sound. The rack-mount unit includes a microphone preamp, compressor, de-esser, microphone and tube modeling, and pitch correction processing.

An XLR microphone input with switchable phantom power is available on the front panel, suitable for use with condenser microphones. Processing is laid out in simple-to-use blocks on the front panel, each with dedicated buttons and meters that display exactly what's being done to the signal at any point in the signal chain.

Antares' microphone and tube modeling can impart the character of another microphone if required, with a library of classic microphone models to choose from. A de-esser module removes sibilance from the signal before being sent on to a variable-knee compressor and gate. Digital EQ is last process in the chain before output.

The Auto-Tune module can be set for any level of pitch correction, in a variety of user-selectable scales. All settings can be recalled through presets on the front panel or through MIDI. Balanced TRS input and outputs are located on the rear panel, including a "Double Track" output for simulating doubled vocals. S/PDIF digital output is also available.

  • Antares Auto-Tune Evo real-time pitch correction with enhanced tracking and correction capabilities
  • Antares Microphone Modeling simulates a variety of high-end studio microphones with variable proximity effect
  • Analog tube modeling effect
  • Variable-knee compression
  • Downward-expanding gate processor
  • Variable frequency de-esser
  • Flexible 2-band parametric EQ
  • Automatic mono or stereo double tracking
  • User-programmable settings
  • Dynamic MIDI control
  • XLR microphone input with phantom power
  • 1/4" balanced line input and output
  • S/PDIF digital output
  • 1/4" footswitch input
  • Microphone Modeler
Source Microphones
Specific
  • Shure SM58
  • Shure SM57
  • Shure Beta 58a
  • Shure KSM 32
  • Audio Technica 3035
  • Audio Technica ATM31
  • Audio Technica ATM41a Audio Technica ATM4050
  • Rode NT1
  • Rode NT2
  • Rode NT3
  • CAD M177
  • CAD E200
  • CAD E350
Generic
  • Hand held dynamic
  • Studio dynamic
  • Wireless
  • Small diaphragm condenser
  • Large diaphragm condenser

Model Microphones
  • Hand held dynamic
  • Studio dynamic
  • Wireless
  • Small diaphragm condenser 1
  • Small diaphragm condenser 2
  • Large diaphragm condenser 1
  • Large diaphragm condenser 2
  • Large diaphragm condenser 3 Drum microphone - kick
  • Drum microphone - snare
  • Drum microphone - cymbal

Tube Saturation Drive
  • 0.0dB to 12dB

TASCAM TA-1VP Specs
Type Vocal processor
Tuning Chromatic and 24 diatonic scales, all user customizable
Retune speed
Pitch detection sensitivity
Processing and Effects Intonation
Modeling
EQ
Compression
De-esser
Gate
Compressor Threshold: -36dB to 0.0dB
Ratio: 1:1 to 99:1
Attack: 1mS to 200mS
Release: 1mS to 200mS
Knee: Continuously variable
Gate Threshold: -96dB to 0.0dB
Ratio: 1:1 to 99:1
De-Esser Threshold: -60dB to 0.0dB
Ratio: 1:1 to 99:1
Attack: 1mS to 200mS
Release: 20mS to 2.5S
High-Pass Frequency: 2.97kHz to 20kHz
Equalizer 2 Independent Parametric Bands
6dB low-pass
6dB high-pass
12dB low-pass
12dB high-pass
Bandpass
Notch
Low-shelf (variable slope)
Highj-shelf (variable slope)
Peaking
Double tracking
Stereo or variable mono mix
Preset/User Programs 35 preset/user
Inputs 1 x XLR Microphone
1 x 1/4" TRS phone Line
1 x 5-pin DIN MIDI
1 x 1/4" TS phone Pedal Input
Input Impedance Microphone
2.2kΩ
Line
10kΩ
Input Level Microphone
Trim: 0.0dB to +30dB
Nominal (PAD): -56.5dBu (0.001Vrms) to -26.5dBu (0.037Vrms)
Nominal: -20.5dBu (0.073Vrms) to +9.5dBu (2.314Vrms)
Maximum: +9.5dBu (2.314Vrms)
Line
Nominal: 8dBu (1.947Vrms) to 24dBu (12.283Vrms)
Maximum: 24dBu (12.283Vrms)
Output 2 x 1/4" TRS phone
1 x RCA coaxial S/PDIF
1 x 5-pin DIN MIDI
Output Impedance Line
100Ω
Digital
75Ω
Output Level Line
Nominal: +4dBu (1.228Vrms)
Maximum: +20dBu (7.75Vrms)
Digital
0.5Vpp/75Ω
Frequency Response 20Hz to 20kHz, +/-0.5dB (@ line output)
Noise SNR: 98dB or better (@ line output)
THD 0.008% or less (@ line output)
Dynamic Range 120dB or better (@ line output)
Display 20 x 2 character LCD
5 x LED input level
5 x LED output level
4 x LED tuning correction
5 x LED compressor gain reduction
5 x LED de-esser gain reduction
Operating Temperature 41 to 95°F (5 to 35°C
Power Requirements 12VDC via TASCAM PS-1225L AC adapter (included)
Dimensions 19 x 5 x 1.73" (483 x 128 x 44mm)
Weight 4.4 lbs (2kg)
Packaging Info
Package Weight 6.6 lb
Box Dimensions (LxWxH) 21.5 x 11.7 x 5.4"
