Play High Quality Audio Sources Easily Using Bluetooth®
Wireless Playback of a Variety of Audio File Formats from Devices that Support Bluetooth®
Through the antenna located in the front of the CD-200BT, audio file playback signals can be received from a variety of Bluetooth® compatible devices. The types of files that can be played back depend on the transmitting device; so any file type that can be played back by iTunes, Windows Media Player, smartphone player apps and other music applications can be played through this unit. Bluetooth® playback uses a wireless connection, so no new wiring is necessary to use compatible audio sources as long as they are in signal-range, allowing easy and speedy playback.
Device Selection Function Allows Transmission Devices to Be Registered in Advance for Quick Switching and Operation
Bluetooth® playback requires pairing. Normally, pairing is one to one, but the CD-200BT has a device selection function that can be used to pair with multiple transmitting devices. By registering devices to be used in advance, you can switch smoothly between transmission devices for playback with minimal connection interruption time. (Only one device can be used for playback at a time) In addition, since the name of the transmission device currently being used for audio playback can be shown on the display, you can check the connection status within this unit.
Wireless Playback with High Quality Audio
A variety of different profiles are used for Bluetooth® transmission depending on the application. The CD-200BT supports the A2DP (Advanced Audio Distribution Profile) for high audio quality music playback, and SBC (Sub Band Codec), a standard A2DP codec. In addition, it supports the aptX® codec, making high quality wireless audio playback possible. The aptX® codec also has an error recovery function, so audio is much less likely to be interrupted, compared to ordinary SBC transmission.
High-Quality CD Drive Designed and Built by TEAC
All models in the CD-200 series have the same highly-regarded and reliable TEAC designed CD drive. By undertaking development ourselves and including our drives in the player, we have achieved higher dependability, quality and reputation.
Supports for Numerous Audio Formats
The CD-200BT is perfect for any install scenario where audio format versatility is needed.
10-Second Shockproof Memory Prevents Skipping from Vibrations and Other Causes
The 10-second shockproof memory prevents skipping from vibration and other causes. Data stored in the player's memory can be played back without skipping, preventing undesired interruptions.
- Disc Capacity: 1
- Media Type Supported: CD-RW
- Formats Supported: CD-DA
- Formats Supported: WAV
- Formats Supported: MP3
- Formats Supported: MP2
- Formats Supported: CD-Text
- Headphone: Yes
- Auxiliary Input: Yes
- Input Voltage: 120 V AC
- Form Factor: Rack-mountable
- Height: 3.7"
- Width: 18.9"
- Depth: 11.7"
- Weight (Approximate): 9.90 lb
- Environmentally Friendly: Yes
- Environmental Certification: RoHS
- Environmental Certification: WEEE
- Country of Origin: China
|Playback media||CD, CD-ROM, CD-R, CD-RW (12cm / 8cm)|
|CD-DA||Stereo, 44.1kHz, 16-bit|
|WAV||Stereo, 8k / 11.025k / 12k / 16k / 24k / 32k / 44.1k / 48k Hz, 8/16-bit|
|MP2||Stereo, 32k / 44.1k / 48k Hz, 32k to 384k bps|
|MP3||MPEG1 Audio Layer III, 32k / 44.1k / 48k Hz, 32k to 320k bps, VBR|
|Analog audio input|
|Connector||1/8" (3.5mm) Stereo mini jack × 1|
|Nominal input level||–20dBV|
|Maximum input level||–4dBV|
|Analog audio output|
|Connector||RCA Pin jack × 1 pair|
|Nominal output level||–10dBV (0.32Vms)|
|Maximum output level||+6dBV (2.0Vms)|
|Digital audio output|
|Connector||RCA Pin jack × 1|
|Connector||TOS (JEITA RC-5720C) × 1|
|Connector||1/4" (6.3mm) Stereo phone jack × 1|
|Maximum output level||20mW + 20mW or more (THD+N 0.1% or less, into 32Ω loaded)|
|Dimensions (W×H×D)||18.9" × 3.7" × 11.7" / 481 × 94.5 × 298 mm|
|Weight||11.5 lbs. / 5.2 kg|
|Operating temperature||41˚F to 95˚F / 5 ˚C to 35˚C|
|Inclination of installation||5˚ or less|
|Backup Memory Items||Elapse time / Title display setting (CD), Playback mode (CD), Program (when loaded), Current folder (when CD loaded), Current source, Repeat playback function setting (ON/OFF), Pitch control (ON/OFF, CD) Pitch control value (CD)|
|Standard accessories||Wireless remote controller (RC-CD200iL), AA battery × 2, Rack mounting screw, Warranty card, Owner's manual|
|Frequency response||20Hz to 20kHz, ±1dB (playback, JEITA)|
|Distortion||0.01% or less (during playback, JEITA)|
|S/N ratio||90dB or more (playback, JEITA)|
|Dynamic range||90dB or more (playback, JEITA)|
|Channel separation||90dB or more (playback, JEITA)|
