Tannoy VXP 12-WH-UL 12" Dual Concentric Powered Sound Reinforcement Loudspeaker (White) - TA-VXP12-WH

Availability: Call for Availability
Availability: Direct Ship
Tannoy SKU: TA-VXP12-WH
No reviews
Price:
$1,599.00

Description

The VXP 12-WH Dual Concentric Full Range Loudspeaker boasts an exceptional performance-to-size ratio – plus includes
LAB GRUPPEN IDEEA Class-D amplification. VXP 12-WH provides a compact, yet punchy and sonically articulate solution for small-scale performance sound reinforcement, as well as more demanding background music and high-intelligibility speech applications where clarity and natural vocal reproduction are paramount. Thanks to its twin driver design and flexible mounting options, the VXP 12-WH is also ideally suited for use complimenting much larger systems, making it an excellent choice for both installed and
portable applications.



Features

  • Full range multi-purpose powered sound reinforcement loudspeaker for portable and installation applications

  • 1,600 Watt power featuring Lab Gruppen IDEEA electronics Class-D amplification

  • 12" Dual Concentric full range driver for point source phase coherence

  • Tightly controlled 90" dispersion for optimum coverage and forward projection

  • Ideal for FOH, floor monitor and side fill applications

  • Switchable full range or high pass filter operation

  • Vented and internally braced plywood enclosure

  • Finished with hard wearing semi matt white paint

  • Rugged powder coated perforated steel mesh grille

  • Blanking plate for optional VTH pole mount

  • Versatile mounting via optional custom designed hardware

  • Fully balanced input and link output on Neutrik* XLR connectors

  • Neutrik powerCON* for a secure locking mains power connection

  • 10-Year Warranty Program*

  • Designed and engineered in the U.K.

Data Sheet

System
Frequency response

70 Hz - 25 kHz ±3 dB
58 Hz - 30 kHz -10 dB
Nominal dispersion

75° conical @ -6 dB points
Directivity factor (Q)

9.7
Directivity index (DI)

9.9
Power handling (IEC)
Passive

400 W continuous, 1,600 W peak
Bi-amp

LF: 400 W continuous, 1,600 W peak
HF: 80 W continuous, 320 W peak
Sensitivity

99 dB (1 W @ 1 m)
Maximum SPL
Passive

125 dB continuous, 131 dB peak
Bi-amp

LF: 126 dB continuous, 132 dB peak
HF: 125 dB continuous, 131 dB peak
Impedance
Passive

8 Ω
Bi-amp

8 Ω
8 Ω
Crossover Type

Passive / Bi-amp switchable
Components

1 x 15" (380 mm) constant directivityPowerDual
Enclosure
Connectors

2x Neutrik speakON* NL4
1 x barrier strip terminals
Wiring
Passive

Pins 1+ / 1- Input, Pins 2+ / 2- Link
Bi-Amp

Pins 1+ / 1- LF, Pins 2+ / 2- HF
Dimensions H x W x D

591 x 451  x 421 mm
(23.3  x 17.8 x 16.6")
Net weight

25.5 kg (56.2 lbs)
Construction

18 mm (3/4") enclosure / 18 mm (3/4") front,
plywood, vented and internally braced
Finish

Semi matt black paint (white optional)
Grille

Powder coated perforated steel
Flying hardware

M10 x 8 flying inserts
(portrait or landscape mounting)
M10 x 8 yoke bracket inserts
2 x Intergrip carrying handles
Blanking plate for optional VTH pole mount
Compatible with industry standard brackets
M6 x 4 inserts
Accessories
Yoke Horizontal VX15<br />Yoke Vertical VX15<br />VTH Top Hat
