Tannoy DVS 6-WH 6" Coaxial Surface-Mount Loudspeaker (White,Pair) - TA-DVS6-WH

Tannoy SKU: TA-DVS6-WH
No reviews

Price:
Sale price$438.00

Description

(Sold as a pair)

DVS 6-WH

Designed to excel in a wide variety of sound reinforcement applications, the full range DVS 6-WH is an ultra compact 240-Watt surface mount loudspeaker that provides both exceptional value and inspiring acoustic performance. The DVS 6-WH is ideally suited for stereo or mono background/foreground music applications in theme parks, hotels, restaurants and bars, retail stores, as well as corporate AV, residential developments, and houses of worship.



  • Full range surface-mount loudspeaker for indoor and outdoor installation applications

  • 60 Watts continuous, 240 Watts peak power

  • 6" mineral loaded polypropylene driver with nitrile rubber surround for enhanced durability and long-term reliability

  • 0.75" ferrofluid cooled soft dome neodymium high frequency driver

  • 90° constant directivity dispersion for optimum coverage

  • UL 1480 certified for general signalling systems

  • UV and weather resistant UL 94 V-0 ABS enclosure

  • 6 Ohm direct input for low impedance applications

  • All components weather resistant to IP64 for outdoor use

  • Stylish durable enclosure in a semi matt white paint finish fits unobtrusively in any environment

  • Painted perforated aluminium mesh grille with dust protection

  • Yoke bracket included for ease of installation

  • Phoenix* connectors input and link output

  • 10-Year Warranty Program*

  • Designed and engineered in the U.K.

Data Sheet



Performance
Frequency response (-3 dB)1

80 Hz - 20 kHz

Frequency response (-10 dB)1

65 Hz - 30k Hz

System sensitivity (1 W @ 1 m)2

88 dB

Dispersion (-6 dB)

90 degrees conical

Transducers

Coaxial

Low frequency

165mm (6.5") mineral loaded cone material

High frequency

20 mm (0.79)

Crossover

4.3 kHz - 2nd order LF, 2nd order HF

Directivity (Q)

10.6 averaged 1 kHz to 10 kHz

Directivity (DI)

9.6 averaged 1 kHz to 10 kHz

Rated maximum SPL 2

105 dB (average)
111 dB (peak)

Non Transformer Version
Maximum wire gauge for connector

2.5 mm CSA (AWG12)

Safety Agency Ratings

UL-1480, CE

Power Handling
Average

60 W

Programme

120 W

Peak

240 W

Recommended amplifier power

120 W @ 6 Ohms

Nominal impedance

6 Ohms

Construction
Enclosure

ABS

Grille

Aluminium, painted

Connectors

Euroblock type removable locking connector with screw terminals with “loop through” facility

Supplied accessories

Yoke bracket

Packed quantity

2

Dimensions (H x W x D)

340.5 x 212.2 x 216.5 mm
(13.41 x 8.36 x 8.52")
