Tannoy CVS 801S LZ 8" Ceiling Subwoofer Loudspeaker (White,Pair) - TA-CVS 801S LZ-WH
Tannoy CVS 801S LZ 8" Ceiling Subwoofer Loudspeaker (White,Pair) - TA-CVS 801S LZ-WH is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Tannoy CVS 801S LZ 8" Ceiling Subwoofer Loudspeaker (White,Pai...
Product Overview
The Tannoy CVS 801S LZ is an 8-inch low-impedance ceiling subwoofer finished in white and sold as a pair. It adds extended low-frequency output to distributed background and foreground music systems, complementing full-range ceiling loudspeakers in commercial installations. UL 1480 and UL 2043 certifications qualify it for fire-protected signalling and air-handling plenum spaces where code compliance is a priority.
Product Description
The CVS 801S LZ is a low-impedance (8-ohm) ceiling subwoofer engineered to extend bass in both background and foreground music systems. An 8-inch polypropylene long-excursion driver with a butyl rubber surround delivers deep, low-distortion bass output with the durability needed for constant commercial use. An acoustic low-pass baffle design allows the subwoofer to be used without an external crossover, simplifying system design and integration with full-range ceiling speakers. The 8-ohm direct input runs it on standard low-impedance amplifier channels. A UV- and weather-resistant UL 94 V-0 ABS front combines with a plated steel fire-can enclosure, and a steel cover with strain-relief clamping accommodates fire-rated cable. The semi-matt white finish and powder-coated aluminium mesh grille blend into most ceilings, and the included mounting C-ring and ceiling tile rails speed installation. It carries UL 1480 and UL 2043 certifications, a 10-year warranty, and is engineered in the U.K. Browse the full Tannoy collection for matching full-range ceiling loudspeakers and amplifiers.
Key Features
- 8-inch long-excursion driver — A polypropylene cone with butyl rubber surround delivers extended deep bass with low distortion and long-term durability.
- Crossover-free operation — The acoustic low-pass baffle design allows the subwoofer to be used without an external crossover.
- 8-ohm low-impedance input — Direct low-impedance operation integrates with standard amplifier channels.
- 400 W peak power handling — Rated at 100 W continuous and 400 W peak for substantial low-frequency headroom.
- UL 2043 plenum certification — Air-handling space certification permits installation above suspended ceilings in return-air plenums.
- Fire-can enclosure — A plated steel fire can and strain-relief clamp for fire-rated cable support life-safety installations.
- Tile-ready mounting — The included C-ring and ceiling tile rails speed fitting into suspended ceilings.
- 10-year warranty — Backed by Tannoy's 10-Year Warranty Program.
Typical Applications
- Conference room
- Commercial meeting space
- Multi-purpose room
- House of worship
- Auditorium
Technical Specifications
| Type | Low-impedance ceiling subwoofer |
| Driver | 8" polypropylene long-excursion, butyl rubber surround |
| Power handling (continuous / peak) | 100 W / 400 W |
| Nominal impedance | 8 Ohms (low impedance only) |
| Crossover | Acoustic low-pass baffle (no external crossover required) |
| Enclosure | UL 94 V-0 ABS front with plated steel fire can |
| Grille | Powder coated aluminium mesh |
| Finish | Semi matt white |
| Compliance | UL 1480, UL 2043 |
| Included accessories | Mounting C-ring, ceiling tile rails |
| Warranty | 10-Year Warranty Program |
Frequently Asked Questions
Is the CVS 801S LZ sold as a pair?
Yes, this listing supplies two ceiling subwoofers.
Does it require an external crossover?
No. Its acoustic low-pass baffle design lets it operate without an external crossover, simplifying integration with full-range ceiling speakers.
Can it run on 70V/100V distributed lines?
No. This is a low-impedance (8-ohm) model intended for low-impedance amplifier channels only.
Is it rated for air-handling plenum spaces?
Yes. It carries UL 2043 certification for air-handling spaces and UL 1480 for fire-protected signalling systems.
What warranty and support are included?
It is covered by Tannoy's 10-Year Warranty Program. Contact Creation Networks for system design support and a project quote.
