Tannoy CVS 601 6.5" Coaxial In-Ceiling Loudspeaker (White, Pair) - TA-CVS 601

Product Overview

The Tannoy CVS 601 is a 6.5-inch coaxial in-ceiling loudspeaker, sold as a pair, built for background and foreground music in commercial interiors. With wide constant-directivity coverage and multiple 70V/100V transformer taps, it suits distributed audio in restaurants, hotels, houses of worship, and retail. EN 54-24 and UL certifications also make this ceiling speaker appropriate for fire-protected signalling and voice-alarm systems where life safety is a priority.

Product Description

This listing is for a pair of CVS 601 loudspeakers. Each unit combines a 6.5-inch polypropylene driver with butyl rubber surround and a 0.75-inch ferrofluid-cooled soft-dome high-frequency driver on a coaxial axis, delivering a coherent point-source response with the power handling, wide frequency range, and low distortion usually associated with more expensive products. Rated at 50 watts continuous and 200 watts peak, the CVS 601 maintains intelligibility at both background and foreground music levels. A low-insertion-loss 30W line transformer offers multiple taps for 70V and 100V distributed systems or 8-ohm direct connection. The loudspeaker carries EN 54-24:2008 Type A certification for fire detection and alarm systems, UL 1480 certification for fire-protected signalling, and UL 2043 certification for air-handling plenum spaces, making it a strong choice where both music and life-safety paging share one system. The UL 94 V-0 and 94-5VB ABS front with a plated-steel fire can, an aluminium mesh grille with dust protection, and a fire-rated cable clamp support code-compliant installation. Mounting C-rings and ceiling-tile rails are included for fast fitting. Explore the full Tannoy collection at Creation Networks to match it with compatible subwoofers and amplification.

Key Features

• Coaxial point-source design — A 6.5-inch driver and 0.75-inch soft-dome tweeter share a single axis for coherent, even coverage.
• EN 54-24 Type A certified — Certified for fire detection and fire alarm systems, suiting it to voice-alarm and life-safety installations.
• UL 1480 and UL 2043 listed — Certified for fire-protected signalling and for use in air-handling plenum spaces above the ceiling.
• Multi-tap 70V/100V transformer — A 30W line transformer with accessible taps supports 70V and 100V systems or 8-ohm direct connection.
• 200W peak power handling — Rated at 50 watts continuous and 200 watts peak for reliable output at foreground music levels.
• Plated-steel fire can enclosure — A UL 94 V-0 / 94-5VB ABS front with a plated-steel fire can meets installation fire-rating requirements.
• Fast-fit mounting hardware — Mounting C-rings, ceiling-tile rails, and a fire-rated cable clamp are included to speed installation.
• 10-year warranty program — Backed by Tannoy's long-term warranty for dependable commercial service.

Typical Applications

• House of worship
• Commercial meeting space
• Multi-purpose room
• Conference room

Technical Specifications

Frequently Asked Questions

Is the CVS 601 sold individually or as a pair?
This listing is for a pair of CVS 601 loudspeakers.

Can it run on a 70V or 100V distributed system?
Yes. The 30W line transformer provides multiple 70V and 100V taps, and the loudspeaker can also be connected directly at 8 ohms.

Is the CVS 601 suitable for life-safety voice alarm?
Yes. It is EN 54-24:2008 Type A and UL 1480 certified, making it appropriate for fire detection and fire-protected signalling systems.

Can it be installed in a plenum ceiling?
Yes. UL 2043 certification allows installation in air-handling spaces above the ceiling.

What support is available for system design?
Creation Networks can help with tap selection, amplifier sizing, and coverage planning. Contact us for a project quote.
