Tannoy CMS 801 SUB PI 8" Compact Ceiling-Mounted Subwoofer (Pre-Install,Pair) - TA-CMS801SUB-PI

Availability: Call for Availability
Availability: Direct Ship
Tannoy SKU: TA-CMS801SUB-PI
No reviews
Price:
$758.00

Description

(Sold as a pair)

The CMS 801 SUB PI is a compact 400- Watt subwoofer that complements the entire range of CMS ceiling monitor systems. Thanks to a powerful 8" long excursion LF driver, the UL certified CMS 801 SUB PI delivers dynamic low frequency extension and premium grade audio for music and speech reinforcement applications.



  • Compact ceiling subwoofer for installation applications

  • 100 Watts continuous, 400 Watts peak power

  • 8" long excursion driver for greater low frequency response

  • Pre-install version supplied without back can (available separately)

  • Multiple transformer taps for 70 V and 100 V line systems or 6 Ohm direct input when used with the optional CMS 801 OHM PI BACKCAN

  • UL 1480 certified for general signalling systems

  • UL 2043 certified for air-handling spaces

  • Low insertion loss 60 W line transformer with easily accessible tapping switch. Note that the transformer is mounted in optional CMS 801 PI 8 OHM BACKCAN

  • Semi matt white finish fits unobtrusively in any environment

  • Powder coated UV resistant perforated steel mesh grille with dust protection

  • Removable grille for custom painting

  • Self-aligning 5 way clamp mounting system

  • Mounting C-ring and ceiling tile rails included

Data Sheet



System
Frequency response (-3 dB) <sup>(1)</sup>

58 Hz - 160 Hz
Frequency range (-10 dB) <sup>(1)</sup>

42 Hz - 300 Hz
System sensitivity (1 W @ 1 m) <sup>(2)</sup>

92 dB (1 W = 2.45 V for 8 Ohms)
Rated maximum SPL <sup>(2)</sup>

112 dB (average) 118 dB (peak)
With THP60

110 dB (average)
Power handling <sup>(3)</sup>
Transformer taps (via front rotary switch)
Transducers
Low frequency / High frequency

1x 200 mm (8.00") long throw woofer with multi fibre paper pulp cone
Enclosure
Backcan Options
Safety agency ratings (pending)

UL-1480, UL-2043, CE
PI hole cutout diameter

295 mm (11.61")
Dimensions
Bezel diameter

325 mm (12.80")
Back of ceiling surface to rear of back can (PI)

151.2 mm (5.95")
Back of ceiling surface to top of safety loop (PI)

168.5 mm (6.63")
Front of ceiling to rear of bass ports (no back can) PI

123.7 mm (4.87")
Net Weight (ea)
Included Accessories

C Ring, tile bridge, paint mask, cutout template, grille
Optional Accessories

Plaster (Mud) Ring
Ordering Information
Model name

CMS 801 SUB PI
Baffle / Grille Colour

WHITE
Packed Quantity

2
Packed weight kg (lbs)

12.2 (26.84)
