Tannoy Back Can for CMS 503 PI Series Ceiling Loudspeakers (Pre-Install) - TA-CMS503-PI-BC
Tannoy Back Can for CMS 503 PI Series Ceiling Loudspeakers (Pre-Install) - TA-CMS503-PI-BC is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Tannoy Back Can for CMS 503 PI Series Ceiling Loudspeakers (Pre-Ins...
Product Overview
The Tannoy CMS 503 PI back can (TA-CMS503-PI-BC) is an acoustically enhanced pre-install enclosure for CMS 503ICT PI and CMS 503DC PI ceiling loudspeakers in newly constructed, non-suspended ceilings. This zinc-plated steel back can lets AV integrators pre-wire and rough-in loudspeaker locations before the ceiling is finished, streamlining project scheduling. Its low-profile design suits shallow ceiling voids in commercial construction.
Product Description
The CMS 503 PI BACKCAN is an acoustically enhanced zinc-plated steel back can designed for the pre-installation of CMS 503ICT PI and CMS 503DC PI loudspeakers in newly constructed, non-suspended ceilings. Early installation of the low-profile back can is fast and simple via the included flexible metal straps, significantly reducing the time required for project finalization. The back can and containment can be installed prior to completion of the ceiling, allowing electrical and AV trades to coordinate rough-in work efficiently. Phoenix connectors are provided for input and link output, supporting clean daisy-chained wiring across multiple ceiling loudspeakers. Optional plaster (mud) rings are available separately to identify pre-wiring locations on site. This accessory is part of the Tannoy CMS ceiling loudspeaker ecosystem and is intended for installers specifying pre-install ceiling audio in commercial construction. Browse the full Tannoy collection for compatible CMS loudspeakers and accessories. The back can is covered by Tannoy's 10-Year Warranty Program and is designed and engineered in the U.K.
Key Features
- Acoustically Enhanced Enclosure — An acoustically enhanced zinc-plated steel back can purpose-built for CMS 503 PI Series ceiling loudspeakers.
- Pre-Install Design — Designed for pre-installation in newly constructed non-suspended ceilings, with back can and containment fitted before the ceiling is completed.
- Low Profile — A low-profile form factor eases installation in shallow ceiling voids common to commercial construction.
- Flexible Metal Straps Included — Includes flexible metal straps for secure, fast fixing of the back can during rough-in.
- Phoenix Connectors — Provides Phoenix connectors for input and link output to support daisy-chained loudspeaker wiring.
- Optional Plaster Ring — An optional plaster ring (available separately) identifies pre-wire locations on site.
- 10-Year Warranty Program — Backed by Tannoy's 10-Year Warranty Program for long-term installation confidence.
- U.K. Engineered — Designed and engineered in the U.K. for commercial-grade reliability.
Technical Specifications
| Model | TA-CMS503-PI-BC (CMS 503 PI BACKCAN) |
| Type | Pre-install back can |
| Compatibility | CMS 503ICT PI and CMS 503DC PI ceiling loudspeakers |
| Material | Acoustically enhanced zinc-plated steel |
| Application | Newly constructed, non-suspended ceilings |
| Fixing | Included flexible metal straps |
| Connectors | Phoenix connectors for input and link output |
| Warranty | 10-Year Warranty Program |
| Origin | Designed and engineered in the U.K. |
