Tannoy Back Can for CMS 1201 Series Ceiling Loudspeakers - TA-CMS1201-BC

Product Overview

The Tannoy CMS 1201 back can is an acoustically enhanced ceiling loudspeaker back can for the CMS 1201DC. This zinc-plated steel enclosure is designed for pre-installation in newly constructed suspended and non-suspended ceilings, giving AV integrators a way to rough-in containment and mounting before the ceiling is finished. Its internally damped 79-litre volume supports strong low-frequency performance in commercial and architectural installations.

Product Description

The CMS 1201 BACKCAN is an acoustically enhanced, zinc-plated steel back can engineered for pre-installation of CMS 1201DC loudspeakers in new construction. The back can and containment can be fitted before the ceiling is completed, which lets integrators sequence rough-in work ahead of final finishing and reduces project turnaround. Its internally damped 79-litre (2.8 cubic feet) volume provides exceptional low-frequency performance for the paired loudspeaker. Multiple installation methods are supported: steel mounting lugs for fitting to a Unistrut roof-rail system, suspension via four top-mounted eye bolts, or single-point suspension on M10 or 3/8-inch UNC threaded rod. The time-saving design enables one-person installation, and Phoenix connectors are provided for input and link output to simplify daisy-chained wiring. This accessory is part of the wider Tannoy collection at Creation Networks and is intended for use with the CMS 1201DCT loudspeaker driver. It is finished in powder-coated zinc-plated steel for durability in commercial ceiling voids.

Key Features

• Acoustically enhanced enclosure — An internally damped 79-litre (2.8 cubic feet) zinc-plated steel back can provides exceptional low-frequency performance for the CMS 1201DC.
• Pre-install design — Intended for installation in newly constructed suspended and non-suspended ceilings before final finishing, supporting efficient project sequencing.
• Multiple mounting options — Steel mounting lugs fit a Unistrut roof-rail system, with hanging via four top-mounted eye bolts or single-point M10 / 3/8-inch UNC threaded rod.
• One-person installation — The time-saving design enables a single technician to complete the mount, reducing labour on large projects.
• Loop-through wiring — Phoenix connectors provide input and link output for straightforward daisy-chained connection.
• Durable construction — Powder-coated zinc-plated steel withstands the conditions of commercial ceiling voids.
• 10-year warranty — Backed by Tannoy's 10-Year Warranty Program for long-term reliability.

Typical Applications

• Conference room
• Auditorium
• House of worship
• Multi-purpose room
• Government space

Technical Specifications

Frequently Asked Questions

Which loudspeaker is this back can for?
It is designed specifically for the Tannoy CMS 1201DC series ceiling loudspeaker driver and provides the acoustic enclosure for that model.

Can it be installed before the ceiling is finished?
Yes. The back can and containment are designed to be installed in new construction prior to ceiling completion, allowing rough-in ahead of final finishing.

How is it mounted?
It supports Unistrut roof-rail lugs, four top-mounted eye bolts for suspension, or single-point hanging on M10 or 3/8-inch UNC threaded rod.

Does it support daisy-chained wiring?
Yes. Phoenix connectors are provided for both input and link output to simplify loop-through connections between units.

What warranty and support are included?
The back can is covered by Tannoy's 10-Year Warranty Program. Contact Creation Networks for compatibility guidance and a project quote.
