SurgeX SX-DS-208 Defender Series 8-outlet Power Conditioner

Product Overview

The SurgeX SX-DS-208 Defender Series is an 8-outlet power protection and conditioning unit built for commercial AV installations where comprehensive protection is required without exceeding a tight budget. Part of the SurgeX Defender Series line developed specifically for everyday AV system applications, the SX-DS-208 ensures that essential power protection is part of every system design regardless of project scale. Engineered to deliver the lowest amount of let-through energy along with over voltage shutdown protection, the SX-DS-208 provides a solid power protection foundation for small commercial AV deployments at an accessible price point.

Product Description

The SurgeX SX-DS-208 brings the Defender Series power protection architecture to AV installations where eight protected outlets are needed and budget considerations are a primary factor in product selection. Designed to prevent the common mistake of omitting power protection from smaller system deployments, the SX-DS-208 establishes a commercial-grade protective baseline for the connected AV equipment.

The over voltage shutdown function automatically disconnects connected equipment when line voltage reaches potentially damaging levels—protecting displays, media players, audio amplifiers, and control hardware from overvoltage events that standard power strips do not address. The emphasis on minimizing let-through energy means that transient events that reach the unit are substantially reduced before they can affect connected equipment, which is the core function that separates commercial power protection products from basic retail surge strips.

For AV integrators building systems in huddle rooms, small conference rooms, and multi-purpose spaces where a higher-tier SurgeX product is not within scope, the SX-DS-208 provides an appropriate, code-defensible power protection specification. It operates on both 120V and 208V systems, giving it applicability across the range of commercial building electrical environments commonly encountered in AV system integration work.

Key Features

• Lowest Let-Through Energy — Reduces surge energy reaching connected equipment to the minimum possible, providing meaningful transient protection at an entry-level price.
• Over Voltage Shutdown Protection — Disconnects connected equipment automatically when line voltage rises to dangerous levels.
• 8-Outlet Configuration — Supports complete small-room AV system deployments from a single power protection unit.
• Commercial-Grade SurgeX Construction — Built to the same quality and reliability standards as higher-tier SurgeX products.
• 120V and 208V Compatibility — Suitable for use across a broad range of commercial electrical environments.
• Budget-Appropriate Power Protection — Ensures essential protection is included in every commercial AV installation regardless of project budget.

Typical Applications

• Huddle room
• Conference room
• Training room
• Commercial meeting space
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

Why specify the SX-DS-208 instead of a retail surge strip for a small AV installation?

Retail surge strips typically use MOV-based protection that degrades after each transient event and provides limited real let-through energy reduction. The SX-DS-208 is built to commercial standards with engineered let-through energy minimization and over voltage shutdown—features that protect AV equipment more effectively and last longer than consumer alternatives.

What type of equipment does the SX-DS-208 protect?

It is suitable for any commercial AV equipment that operates within its outlet and amperage specifications, including flat panel displays, projectors, media players, audio amplifiers, wireless receivers, and control systems.

What does over voltage shutdown do that standard surge protection does not?

Standard surge protection addresses fast transient spikes. Over voltage shutdown addresses sustained overvoltage conditions—when line voltage remains elevated above safe operating levels for an extended period—which can damage equipment even if no sharp spike is present.

Is the SX-DS-208 suitable for both 120V and 208V commercial circuits?

Yes. The 120V/208V compatibility allows it to be deployed across different commercial building electrical configurations without requiring a separate unit for each voltage environment.

What is the difference between the SX-DS-158 and SX-DS-208?

Both are 8-outlet Defender Series units with the same core protection features. Review specific product documentation for form factor, cord length, or mounting differences that may affect installation requirements for a particular project.
