SoundTube SM890I-WX 8" 2-Way Extreme Weather Outdoor Surface Mount Speaker

The SoundTube SM890I-WX is a high-output 8" 2-way outdoor surface-mount speaker built on SoundTube's WX Weather Guard technology platform — the correct specification for commercial outdoor audio installations in the harshest climates. A dual-layer hydrophobic material inside the powder-coated steel grille prevents water from reaching the drivers and internal electronics even during sustained driving rain, making it the appropriate choice for covered outdoor venues, waterfront entertainment areas, and any installation where IP44-rated protection is the minimum acceptable standard. The SM890I-WX's patented BroadBeamHP waveguide technology delivers consistent dispersion patterns for maximum speech intelligibility and edge-to-edge coverage across large outdoor zones — a critical performance attribute for paging applications in stadiums, theme parks, and transportation facilities. Available in black and white to match venue architecture.

Product Images

Description

The SM890I-WX is engineered for short-to-medium throw PA and sound reinforcement applications that demand both high output and weather survivability. The 8" high-efficiency woofer is paired with a 1.38" titanium compression driver mounted behind a proprietary tool-free rotatable 110°85° bayonet-mounted horn, giving installers the ability to precisely tailor dispersion pattern and throw direction after the speaker is mounted — a significant advantage in complex venue geometries where fixed-horn speakers require re-aiming if the speaker position changes. The ABS glass-fiber reinforced injection-molded ported enclosure provides a 1,008 cubic inch internal volume that supports the 80 Hz–22 kHz (±10 dB) frequency response and 8-ohm nominal impedance. At 150 watts continuous RMS and 300 watts program power, the SM890I-WX delivers the sound pressure levels required for foreground music and voice paging in large outdoor venues without amplifier clipping or driver distress. The 150-watt low-insertion-loss transformer covers 25V, 70.7V, and 100V operation with an easy-access 6-position rotary tap switch, providing the system flexibility that commercial integrators require across diverse project types. Sensitivity of 92 dB at 1W/1M produces high output from relatively modest amplifier power, a key advantage in battery-backup emergency systems. Included accessories cover the complete installation: surface-mount bracket, safety cable, Euroblock connector, terminal weather boot, and paint mask. CCC, CE, IP44, RoHS, and UL1480 certifications confirm compliance for international commercial deployment. Creation Networks provides complete outdoor speaker system design for hospitality, sports, and transportation projects; contact our team for coverage analysis and volume pricing.

Key Features

• WX Weather Guard Dual-Layer Hydrophobic Grille — Prevents water intrusion to drivers and internal electronics, enabling reliable performance through sustained rain and high-pressure wash-down without IP rating compromise.
• Patented BroadBeamHP Waveguide Technology — Consistent dispersion pattern maximizes speech intelligibility and edge-to-edge coverage for large outdoor venue paging and music reinforcement.
• Rotatable 110×85° Bayonet Horn (Tool-Free) — Adjustable after mounting to dial in throw direction and dispersion, accommodating complex venue geometries without remounting the enclosure.
• 150W RMS / 300W Program Power — High-power 8" woofer and titanium compression driver deliver the output levels required for large outdoor stadiums, theme parks, and entertainment venues.
• 92 dB Sensitivity — High-efficiency design maximizes sound pressure level per watt, reducing amplifier requirements and enabling effective performance from emergency backup power systems.
• 6-Position Rotary Tap Switch (25/70.7/100V + Bypass) — Front-accessible transformer tap selector covers all common distributed audio voltages plus 8-ohm direct drive for installation flexibility.
• IP44 Rated, ABS Glass-Fiber Enclosure — Injection-molded enclosure resists impact and weathering while IP44 rating confirms protection from solid particles larger than 1mm and water splashing from any direction.
• Full Installation Kit Included — Surface-mount bracket, safety cable, Euroblock connector, terminal weather boot, and paint mask ship with every unit, reducing installation material costs.

Typical Applications

• Stadium concourses and outdoor venue perimeter paging and music reinforcement
• Waterfront entertainment districts, marinas, and boardwalk commercial audio zones
• Theme park ride queues and outdoor entertainment areas requiring reliable high-SPL performance
• Airport and transportation hub exterior public address and paging systems
• Resort pool decks and outdoor restaurant areas requiring foreground music capability
• Sports facility exterior parking and entry areas requiring voice-intelligible paging

Technical Specifications

Frequently Asked Questions

What does WX Weather Guard mean in practice?

WX Weather Guard refers to SoundTube's dual-layer hydrophobic material system incorporated inside the grille. This material repels water before it can reach the woofer cone, tweeter, and internal electronics, providing protection beyond what the IP44 rating alone conveys during sustained rainfall and splash exposure.

Can the horn dispersion be adjusted after mounting?

Yes. The 110°85° horn is bayonet-mounted and rotates without tools, allowing installers to adjust throw direction after the speaker is secured to the mounting bracket. This is a significant time-saving feature during commissioning of complex multi-speaker arrays.

What is the SM890I-WX rated for in terms of transformer voltage?

The built-in 150-watt transformer supports 25V, 70.7V, and 100V operation, plus 8-ohm direct drive. Maximum power settings are 19W (25V), 150W (70.7V), and 150W (100V). The 6-position rotary tap switch is accessible from the front of the enclosure.

How does BroadBeamHP differ from a standard horn design?

SoundTube's patented BroadBeamHP waveguide technology is engineered to maintain a consistent dispersion pattern across a wider frequency range than conventional constant-directivity horns, improving edge-to-edge coverage uniformity and speech intelligibility in large outdoor zones.

Is the SM890I-WX appropriate for emergency paging and mass notification?

Yes. The 92 dB sensitivity and 150W RMS power handling provide the output levels required for voice intelligibility in large outdoor areas. Certification to UL1480 makes it suitable for fire alarm and life safety notification systems where that standard is required.

What colors are available?

The SM890I-WX is available in black (SKU: SM890I-WX-BK) and white (SKU: SM890I-WX-WH). A paint mask is included in the box to facilitate field painting to custom colors if required.

Does the safety cable need to be purchased separately?

No. A safety cable is included in the standard package. An optional 10-foot safety cable (AC-SC-10) is available if a longer cable is needed for the specific mounting configuration.
