Soundtube SM500I-II-WX 5.25" Extreme Weather Outdoor Surface Mount Spkr

Soundtube SKU: SM500I-II-WX-BK
No reviews

Model: Black
Sale price$336.00


SoundTube®'s WX Weather Guard technology utilizes a dual layer hydrophobic material inside the speaker grille to keep water from the drivers and internal electronics in even the most extreme weather conditions. The SM500I-II-WX utilizes the patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity as well as BroadBeam® waveguide technology to deliver a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker. The SM500I-II-WX has one 5.25 inch (133 mm) polypropylene woofer and one 1.0 inch (25 mm) convex titanium tweeter with FerroFluid cooling. The speakers 86.0 dB average sensitivity offers high output capabilities and reduced amplification costs and the six-position selectable tap switch for 25-, 70.7- and 100-volt applications provides easy access. The included SM500i-II-WX Stealth™ bracket mounting system with vertical and horizontal pivoting allow the SM500i-II-WX to be aimed anywhere within the installation space and the low profile enclosure design keeps the speaker close to the wall. Safety cable with speaker mounting bolt, Euroblock connector, wall mount bracket and terminal weather boot are included. IP-Rating: IP44.

Manufacturer SoundTube
Manufacturer's Category SMi Surface Mount
Height 11.4 in / 289.6 mm
Width/Diameter 8.36 in / 212.3 mm
Shipping Weight 10.5 lbs / 4.76 kg
Carton Height 12.25 in / 311.15 mm
Carton Length 13.5 in / 342.9 mm
Carton Width 10.5 in / 266.7 mm
Certifications CE, RoHS, UL1480A
Enclosure Properties ABS Glass Fiber Reinforced, Injection Molded, Ported
Enclosure Volume 349.6 cu in / 5728.92 cu cm
Included Accessories Euroblock, Mounting Hardware, Safety Cable, Terminal Weather Boot
Optional Accessories White Grille (GRL-SM500-II-WX-WH)|10" Safety Cable (AC-SM-SC10)|White Mounting Bracket (AC-SM5-II-WP-WH)|Connector (EUROBLOCK)|White Weatherboot (WEATHERBOOT-S-WH)
Source Inputs 4 Pin 5.08mm Euroblock
IP Rating IP44
Crossover Frequency 3.0 kHz
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) 4.6 and 9.8
Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) 5.6dB and 9.9dB
Frequency Response (± 10 dB) 60 Hz - 22 kHz
Frequency Response (± 3 dB) 86 Hz - 22 kHz
Grille Properties Aluminum, Powder-Coated, Weatherproof
Low Frequency Voice Coil 1 in / 25.4 mm
Low Pass Crossover 12 dB per octave 2nd order
Max. Continuous Power RMS 75W
Max. Program Power 150 W
Minimum Impedance (Ω Ohms) 4 Ω
Mounting Depth 10.48 in / 266.2 mm
Network Type: High Pass 12 dB per octave 2nd order
Nominal Impedance (Ω Ohms) 4 Ω
Tweeter Driver 1" Convex Aluminum w/ BroadBeam® Waveguide
Woofer Driver 5.25" Polypropylene
Sensitivity dB @ 1W/1M 83 dB
Sensitivity dB @ 2.83V/1M 86 dB
Tap Selector Rotary Switch
Transformer Options 25 / 70.7 / 100 V, 4 Ohm direct
Transformer Taps Max. Setting (25V/70.7V/100V) 8W/64W/64W
