Soundtube RS600I 6.5" Hanging Speaker with a BroadBeam Tweeter

Soundtube SKU: RS600I-BK
No reviews
Model: Black
Price:
$385.00

Description

The RS600i has a 6.5-inch polypropylene woofer and one 1.0 inch convex titanium tweeter with FerroFluid cooling mounted to a proprietary cast-aluminum baffle and heat sink. The two-way ported speaker with an open-ceiling enclosure design delivers effective low-end response (58 Hz) and 100° off-axis performance (2 to 10 kHz, indepen-dently verified). The RS600i uses patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity. SoundTube®'s proprietary BroadBeam® waveguide tweeter system delivers consistent high-performance audio across the operating bandwidth. The RS600i speaker design incorporates a low-profile grille, proprietary motor-board and a six-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass positions. Hanging hardware is included and features a SpeedClamp™ self-locking cable grip for fast, easy and secure installation. Euroblock connector and terminal weather boot are included.

Manufacturer SoundTube
Manufacturer's Category RSi Original Pendant
Height 14.31 in / 363.5 mm
Width/Diameter 12.1 in / 307.3 mm
Shipping Weight 17.7 lbs / 8.02 kg
Carton Height 16.5 in / 419.1 mm
Carton Length 15 in / 381 mm
Carton Width 15 in / 381 mm
Certifications CE, MIL Spec, RoHS, UL1480A, UL2239
Enclosure Properties ABS Glass Fiber Reinforced, Injection Molded, Ported
Enclosure Volume 686.7 cu in / 11253 cu cm
Included Accessories Euroblock, Hanging Hardware, Safety Cable, Terminal Weather Boot
Optional Accessories Black Grille (GRL-RS600-BK)|10' Hanging Cable (AC-RS-HH-10)|20' Hanging Cable (AC-RS-HH-20)|50' Hanging Cable (AC-RS-HH-50)|Black Mounting Bracket (AC-RS-SM6-BK)|Connector (EUROBLOCK)|Black Weatherboot (WEATHERBOOT-L-BK)|Beam Clamp (AC-BC1)|Forged Eye Bolt (AC-FE1)|Black Split Loom Tubing (AC-SLT-10-BK)|Snap Link (AC-SL1)
Source Inputs 4 Pin 5.08mm Euroblock
Coverage Angle (±6dB @ 2kHz) 100°
Crossover Frequency 3.0 kHz
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) 4.7 and 7.9
Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) 5.7dB and 9.0dB
Frequency Response (± 10 dB) 58 Hz - 22 kHz
Frequency Response (± 3 dB) 85 Hz - 17 kHz
Grille Properties Powder-Coated, Steel
Low Frequency Voice Coil 1 in / 25.4 mm
Low Pass Crossover 12 dB per octave 2nd order
Max. Continuous Power RMS 90W
Max. Program Power 180 W
Minimum Impedance (Ω Ohms) 4.8 Ω
Network Type: High Pass 12 dB per octave 2nd order
Nominal Impedance (Ω Ohms) 8 Ω
Tweeter Driver 1" Convex Aluminum w/ BroadBeam® Waveguide
Woofer Driver 6.5" Polypropylene Cone w/ Butyl Rubber Surround
Sensitivity dB @ 1W/1M 88.5 dB
Sensitivity dB @ 2.83V/1M 88.5 dB
Tap Selector Rotary Switch
Transformer Options 25 / 70.7 / 100 V, 8 Ohm direct
Transformer Taps Max. Setting (25V/70.7V/100V) 5W/33W/33W
