Soundtube RS600I 6.5" Hanging Speaker with a BroadBeam Tweeter
SoundTube RS600I 6.5" Hanging Speaker with BroadBeam Tweeter
The SoundTube RS600I is a premium 6.5" open-ceiling pendant speaker from the RSi Original Pendant series, delivering exceptional full-range audio performance for commercial distributed audio systems. At the heart of the RS600I is SoundTube's proprietary BroadBeam® waveguide tweeter system — a 1" convex aluminum tweeter with FerroFluid cooling mounted to a cast-aluminum baffle and heat sink that provides consistent, even high-frequency coverage across a wide listening area. Paired with a 6.5" polypropylene woofer in a ZeroReflection™ ported enclosure, the RS600I achieves a frequency response reaching down to 58 Hz with 100° off-axis performance from 2 to 10 kHz, independently verified.
The RS600I incorporates a six-position selectable tap switch for 25V, 70.7V, and 100V distributed audio systems, plus transformer bypass positions for direct 8-ohm wiring. Maximum continuous power handling is 90W RMS (180W program), making this pendant one of the most powerful in the 6.5" class. The patented ZeroReflection™ enclosure minimizes internal standing waves for accurate sound reproduction with exceptional cabinet rigidity, contributing to long-term reliability in demanding commercial environments.
Installation uses a SpeedClamp™ self-locking cable grip for fast, secure, and code-compliant ceiling mounting. Included accessories cover a Euroblock connector, hanging hardware, safety cable, and terminal weather boot. The RS600I carries CE, MIL Spec, RoHS, UL1480A, and UL2239 certifications, reflecting its suitability for demanding commercial and institutional audio installations. Available in black and white.
Key Features
- BroadBeam® Waveguide Tweeter — Proprietary SoundTube technology delivers consistent high-frequency coverage across the full operating bandwidth with 100° dispersion at 2 kHz.
- 6.5" Polypropylene Woofer — Butyl rubber surround handles 90W RMS for robust, full-range output down to 58 Hz.
- ZeroReflection™ Enclosure — Patented technology minimizes internal resonance for accurate, distortion-free sound reproduction and long-term cabinet durability.
- 90W RMS / 180W Program Power — Among the highest power ratings in the 6.5" pendant class for high-output commercial zone coverage.
- 6-Position Tap Switch — Supports 25V, 70.7V, 100V, and 8-ohm direct for flexible integration with any distributed audio infrastructure.
- SpeedClamp™ Cable Grip — UL-listed self-locking installation hardware enables fast, secure, and code-compliant pendant mounting.
- MIL Spec & UL1480A / UL2239 Certified — Meets stringent military and commercial safety standards for institutional and critical facility deployments.
- Cast-Aluminum Baffle & Heat Sink — Provides thermal management for the FerroFluid-cooled tweeter, ensuring consistent performance under continuous load.
Typical Applications
- Open-ceiling restaurants, bars, and entertainment venues requiring high-output pendant audio
- Hotel lobby and atrium installations where wide dispersion and full-range sound are essential
- Convention centers and exhibit halls with high ambient noise environments
- Corporate campus atriums and multi-story open-plan offices
- Performing arts facility lobbies and pre-function spaces
- Military facilities and institutional campuses requiring MIL Spec certification
Technical Specifications
| Specification | Value |
|---|---|
| Woofer Driver | 6.5" Polypropylene Cone w/ Butyl Rubber Surround |
| Tweeter Driver | 1" Convex Aluminum w/ BroadBeam® Waveguide |
| Frequency Response (±3 dB) | 85 Hz – 17 kHz |
| Frequency Response (±10 dB) | 58 Hz – 22 kHz |
| Max Continuous Power (RMS) | 90 W |
| Max Program Power | 180 W |
| Sensitivity (1W/1M) | 88.5 dB |
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 4.8 Ω |
| Coverage Angle (±6 dB @ 2kHz) | 100° |
| Crossover Frequency | 3.0 kHz |
| Transformer Options | 25 / 70.7 / 100 V, 8 Ω direct |
| Transformer Taps (25V/70.7V/100V) | 5W / 33W / 33W |
| Height | 14.31 in / 363.5 mm |
| Width/Diameter | 12.1 in / 307.3 mm |
| Shipping Weight | 17.7 lbs / 8.02 kg |
| Enclosure | ABS Glass Fiber Reinforced, Ported |
| Certifications | CE, MIL Spec, RoHS, UL1480A, UL2239 |
| Available Colors | Black (RS600I-BK), White (RS600I-WH) |
Frequently Asked Questions
Q: What makes BroadBeam® technology different from a standard tweeter?
A: BroadBeam® uses a proprietary waveguide to disperse high frequencies evenly across a 100° arc, eliminating the "hot spot" directly beneath the speaker and ensuring consistent sound quality for listeners at any angle.
Q: How does the RS600I compare to the RS400I?
A: The RS600I uses a larger 6.5" woofer and handles significantly more power (90W vs. 60W RMS), making it the better choice for larger spaces or applications requiring higher SPL.
Q: Is the RS600I suitable for a 100V distributed audio system?
A: Yes. The six-position tap switch includes 100V settings with a maximum tap of 33W, compatible with any standard 100V commercial amplifier.
Q: What hanging cable lengths are available?
A: Optional hanging cables in 10-foot, 20-foot, and 50-foot lengths are available as accessories (AC-RS-HH-10, AC-RS-HH-20, AC-RS-HH-50).
Q: Is the RS600I MIL Spec certified?
A: Yes. The RS600I carries MIL Spec certification in addition to CE, RoHS, UL1480A, and UL2239, making it appropriate for military base and government facility installations.
Q: Can I get project pricing through Creation Networks?
A: Absolutely. Contact our team at creationnetworks.net for project quotes, system design, and volume purchasing support.
