Soundtube RF31-EZ-T 3" Neo Motor Ceiling Speaker with Transformer

Soundtube SKU: RF31-EZ-T-BK
No reviews
Model: Black
Price:
$113.50

Description

The RF31-EZ-T is a premium full-range 3 inch speaker with a 10 watt transformer for applications requiring 25, 70, and 100 volt audio solutions. The RF31-EZ-T mounts in most dual-gang junction boxes. The RF31- EZ-T incorporates a low-profile grille with a total visible footprint of 4.75-inch square for ultra-compact installations. All exposed components in the RF31-EZ-T are completely weatherized for indoor and outdoor applications.

Manufacturer SoundTube
Manufacturer's Category RF Raw Frame Series
Height 4.75 in / 120.7 mm
Width/Diameter 4.75 in / 120.7 mm
Shipping Weight 1.05 lbs / 0.48 kg
Carton Height 7 in / 177.8 mm
Carton Length 6.75 in / 171.45 mm
Carton Width 6.5 in / 165.1 mm
Certifications CE, RoHS, UL1480A
Enclosure Properties ABS
Included Accessories Grille, Paint Mask
Optional Accessories Black Grille (GRL-RF31-WH)|Theft-Resistant Grille (AC-RF31-TRG)
Source Inputs Terminal Strip
Coverage Angle (±6dB @ 2kHz) 50°
Cutout Width/Diameter 4 in / 101.6 mm
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) 4.3 and 2.4
Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) 5.4dB and 3.8dB
Frequency Response (± 10 dB) 82 Hz - 22 kHz
Frequency Response (± 3 dB) 170 Hz - 14 kHz
Grille Properties Aluminum, Standard-Flange, White, Paintable, Snap-Fit
Low Frequency Voice Coil 0.75 in / 19 mm
Max. Continuous Power RMS 10W
Max. Program Power 20 W
Minimum Impedance (Ω Ohms) 8 Ω
Mounting Depth 2.11 in / 53.6 mm
Nominal Impedance (Ω Ohms) 8 Ω
Sensitivity dB @ 1W/1M 85 dB
Sensitivity dB @ 2.83V/1M 85 dB
Tap Selector Terminal Block
Transformer Options 25 / 70.7 / 100 V
Visible Diameter 4.75 in / 120.7 mm
Visible Height 4.75 in / 120.7 mm
