SoundTube IPD-HP82-EZ IP-Addressable Speaker in White

Soundtube SKU: IPD-HP82-EZ-WH
No reviews
Price:
$687.50

Description

SoundTube IPD-HP82-EZ IP-Addressable Speaker in White

Dante®-enabled coaxial pendant speaker incorporates one 8.0 inch (203 mm) high power coaxial driver with BroadBeamHP™ compression driver technology for long throw and smooth directivity. Low latency digital audio, power, and control are delivered to the speaker via standard category cable; connection is made on the other end to the STNet-Switch or other PoE / PoE+ switch. The speaker may also be powered via a 24V DC barrel connector for non-PoE installations. Configuration and zoning of the speaker are accomplished via software. Includes hanging hardware with galvanized steel cables and hanging bracket for fast, easy and secure installation. Unit may be hung or mounted direct-to-conduit via locking cover plate. Enclosure constructed of injection molded ABS with fiberglass reinforcement for lasting durability in indoor or outdoor applications. Aluminum grille with protective powder coated finish. Hanging hardware, weather plug, cover plate, and AC-RSEZ-HH-10 are included.

Note: SoundTube IPD speakers are NOT compatible with PoE++. 30W PoE maximum (or 40W maximum with STNet Switch II)

Color Black
UPC 748252177070
Manufacturer SoundTube
Manufacturer's Category STNet IP-Addressable and Dante Series
Height 12.9 in / 327.7 mm
Width/Diameter 12.83 in / 325.9 mm
Shipping Weight 16.5 lbs / 7.5 kg
Carton Height 16 in / 406.4 mm
Carton Length 15 in / 381 mm
Carton Width 15 in / 381 mm
Certifications CE, RoHS, UL60065
Enclosure Properties ABS Glass Fiber Reinforced
Included Accessories Cover Plate, Hanging Hardware, Weather Plug
Optional Accessories Black Grille (GRL-RS82-EZ-BK) | 10' Hanging Cable (AC-RSEZ-HH-10) | 20' Hanging Cable (AC-RSEZ-HH-20) | Black Weatherboot (WEATHERBOOT-L-BK) | Beam Clamp (AC-BC1) | Forged Eye Bolt (AC-FE1) | Black Split Loom Tubing (AC-SLT-10-BK) | Snap Link (AC-SL1)
Source Inputs RJ45 Ethernet Port
Coverage Angle (±6dB @ 2kHz) 135°
Crossover Frequency 2.5 kHz
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) 3.6 and 3.7
Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) 5.6 and 5.7
Frequency Response (± 10 dB) 80 Hz - 22 kHz
Frequency Response (± 3 dB) 110 Hz - 22 kHz
Grille Properties Aluminum, Powder-Coated
Low Frequency Voice Coil 1.5 in / 38.1 mm
Low Pass Crossover 12 dB per octave, 2nd order
Max SPL @ 1M 111 dB
Network Type: High Pass 12 dB per octave, 2nd order
Tweeter Driver 1" Titanium Compression Driver with Waveguide™
Woofer Driver 8" Treated Paper Cone w/ Cloth Surround
