Soundtube CM31-EZ 3" In Ceiling Speaker

Soundtube SKU: CM31-EZ-BK
No reviews
Model: Black
Price:
$126.00

Description

3 inch PREMIUM FULL-RANGE IN-CEILING SPEAKERS. One 3 inch (76.2 mm) full-range high-extrusion, high-fidelity polypropylene driver with butyl rubber surround. Weatherized components for indoor/outdoor applications. Shallow 3.5 inch (88.9 mm) deep all-steel backcan with integrated driver and baffle configuration. Ultra-compact design with a total visible footprint of less than 6.3 inch (160.6 mm)diameter. Rapid installation, blind-mount, fixed-wing mounting mechanism with constant tension design affixing to wall thicknesses ranging from 0.1 in. (2.5 mm) to 1.5 in. (38.1 mm). Corrosion-resistant, powder-coated aluminum grille with snap fit attachment. Ceramic input terminal accepts up to 10 gauge plenum rated signal wire and includes thermal fuse. Suitable for use in voice alarm applications subject to EU regulations EN60849 and BS5839-8. UL 1480 (UEAY) and 2043 approved. Included accessories: Choose between a Tile Bridge or a Pre Construction Bracket. IP-Rating: IP54.

Manufacturer SoundTube
Manufacturer's Category CM-EZ Economical In-Ceiling
Shipping Weight 3.7 lbs / 1.68 kg
Carton Height 8.25 in / 209.55 mm
Carton Length 8 in / 203.2 mm
Carton Width 7.25 in / 184.15 mm
Certifications CE, RoHS, UL1480A, UL2043
Enclosure Properties ABS Glass Fiber Reinforced, Injection Molded, Sealed
Enclosure Volume 60 cu in / 983.22 cu cm
Included Accessories Conduit Clamp, Grille, Paint Mask, Wire Nuts, Choose Between a Tile Bridge or Pre-Construction Bracket
Optional Accessories Black Grille (GRL-CM31-BK)|Tile Bridge (AC-CM31-TB)|Pre-Construction Bracket (AC-CM31-PCB)|Junction Box (Included with pre-construction bracket)
Source Inputs Wire Leads
IP Rating IP54
Backcan Diameter 5.5 in / 139.7 mm
Backcan Height 3.5 in / 88.9 mm
Coverage Angle (±6dB @ 2kHz) 45°
Cutout Width/Diameter 5.5 in / 139.7 mm
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) 4.5 and 3.5
Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) 5.3dB and 5.2dB
Frequency Response (± 10 dB) 115 Hz - 22 kHz
Frequency Response (± 3 dB) 190 Hz - 14 kHz
Grille Properties Aluminum, Black, Standard-Flange, Powder-Coated, Snap-Fit
Low Frequency Voice Coil 0.75 in / 19 mm
Max. Ceiling Thickness 1.5 in / 38.1 mm
Max. Continuous Power RMS 20W
Max. Program Power 40 W
Minimum Impedance (Ω Ohms) 8 Ω
Minimum Ceiling Thickness 0.1 in / 2.5 mm
Nominal Impedance (Ω Ohms) 8 Ω
Fullrange Driver 3" Polypropylene driver with butyl rubber surround
Sensitivity dB @ 1W/1M 85 dB
Sensitivity dB @ 2.83V/1M 85 dB
Tap Selector Rotary Switch
Transformer Options 25 / 70.7 / 100 V, 8 Ohm direct
Transformer Taps Max. Setting (25V/70.7V/100V) 1.3W/10W/30W
Visible Diameter 6.3 in / 160 mm
Visible Height 0.6 in / 15.2 mm
