Soundcraft EPM8 – 8-Channel Analog Mixing Console

Product Overview

The Soundcraft EPM8 is an 8-channel analog mixing console built for live sound and AV installation applications that require clean, high-headroom signal handling in a compact form. Like all EPM Series mixers, it uses the GB30 mic preamp — the same design employed in Soundcraft's professional LX7ii and GB Series consoles — for transparent gain across a 55dB range with +22dB of headroom. The EPM8 is a no-frills analog mixer suited for smaller installations, rehearsal rooms, corporate AV rooms, and portable live sound applications where a straightforward mix console is preferred. It is currently on sale at Creation Networks.

Product Description

The EPM8 has an 8+2 channel frame: 8 mono XLR/TRS combo inputs and 2 stereo line input channels. Each mono input channel carries a 3-band EQ with swept midrange control, a TRS insert point for inline processing, two aux sends, and an FX send. The two auxiliary buses provide independent routing for monitor sends and outboard processing. Phantom power is switchable and available on all XLR inputs for condenser microphone compatibility.

Direct outputs on mono input channels allow individual channels to be sent to a multitrack recorder or DAW without interrupting the mix. Sub-group outputs provide additional routing and grouping flexibility for larger signal chains. The master section includes ten-segment LED metering, solo/PFL monitoring, and RCA phono stereo inputs and record outputs for consumer source integration. A headphone output with level control enables independent monitoring. The EPM8 is rack mountable for permanent installed AV deployments. Available from Creation Networks.

Key Features

• 8+2 Channel Frame — 8 mono XLR/TRS inputs and 2 stereo line input channels.
• GB30 Mic Preamp — High-headroom (+22dB) transparent design, 55dB gain range, from Soundcraft's professional console range.
• 48V Phantom Power — Switchable per input for condenser microphones.
• 3-Band EQ with Swept Mid — Precise tonal control on all mono input channels.
• 2 Auxiliary Buses — Independent monitor and effects send routing.
• TRS Insert Points on All Mono Inputs — Inline dynamics and EQ processing.
• Direct Outputs on Mono Inputs — Per-channel multitrack recording or DAW integration.
• Sub-Group Outputs — Additional routing flexibility for larger signal chains.
• Solo/PFL Monitoring — Individual channel isolation during live events.
• Ten-Segment LED Output Metering — Visual output level monitoring.
• RCA Phono Stereo I/O — Consumer playback and record integration.
• Rack Mountable — Fits standard 19" racks.
• Headphone Output — Independent monitoring with level control.

Typical Applications

• House of Worship
• Music Venues
• Small Auditorium
• Rehearsal Room
• Corporate AV Room
• Live Event Recording

Technical Specifications

Frequently Asked Questions

Does the Soundcraft EPM8 have built-in effects?

No. The EPM8 is a clean analog mixing console. For onboard Lexicon effects, the Soundcraft EFX8 offers the same channel count with a 24-bit Lexicon digital effects processor.

Can the EPM8 record individual channels to a DAW?

Yes. The EPM8 has a direct output on each mono input channel for per-channel routing to a multitrack recorder or digital audio workstation.

How many aux sends does the EPM8 have?

The EPM8 has 2 auxiliary buses per channel, suitable for independent monitor mixes, effects sends, or zone routing.

Is the EPM8 rack mountable?

Yes. The EPM8 supports standard 19" rack mounting for permanent installed AV environments.

What is the difference between the EPM8 and EPM12?

The EPM12 has 12 mono input channels while the EPM8 has 8. Both share the same GB30 preamp, 3-band swept mid EQ, 2 aux buses, and direct output architecture.
