Sound Control Technologies RTK-MINI – RemoteTableKit MINI BYOM Table Extension Kit

Product Overview

The Sound Control Technologies RTK-MINI is a compact conference table extension kit that delivers power, HDMI video, USB, and Ethernet from the conference table to the codec over a single CAT cable up to 100 meters — no configuration required. Built on SCTLink technology, it supports USB codecs and video bars such as the Cisco Room Kit Mini and Webex Room USB, and provides PoE for a connected touch panel. For AV integrators, the RTK-MINI is a straightforward way to add BYOM laptop connectivity at the table in huddle rooms and small-to-medium conference rooms.

Product Description

The RTK-MINI pairs a TX module at the table with an RX module at the codec or video bar, consolidating HDMI, USB, and network runs into one CAT5e or CAT6 cable up to 328 feet (100 meters). The platform supports any codec or video bar with a standard USB connection, with the exception of USB DisplayLink-enabled devices; for DisplayLink codecs, Sound Control Technologies offers the RCU3SL USB 3.2 extension system.

At the table, the kit provides HDMI input for laptop content, a USB link for BYOM meetings, Ethernet, and passive PoE (48VDC, 7W, Class-2, Mode B per IEEE 802.3af) to power a touch panel. Video runs up to 4K 25/30 4:4:4 with HDMI embedded audio and HDCP 2.2 support. The RX end includes a three-port 10/100 Layer 2 Ethernet switch (one port with PoE), and the USB 2.0/UVC link can run in either orientation — receiver to transmitter or transmitter to receiver — using one hub tier per linked set.

Everything needed ships in the kit: both modules, two HDMI cables, two UTP cables, USB Micro-B to USB-A and USB-A to USB-C cables, the WPS-12 power supply, and two sets of table kit brackets for clean under-table mounting. A 3-year limited advance replacement warranty is included. A Poly Studio X-Series configuration is available as the RTK-MINI-X30, and rooms needing full USB-C DP Alt Mode with 60W laptop charging should consider the RTK-AM1 RemoteTableKit.

Key Features

• Single-Cable Table Extension — Delivers power, HDMI video, USB, and Ethernet between the table and codec over one CAT cable using SCTLink.
• 100-Meter Reach — Runs up to 328 feet over a single CAT5e or CAT6 STP/UTP cable.
• Universal USB Codec Support — Works with USB codecs and video bars including Cisco Room Kit Mini and Webex Room USB (DisplayLink devices excepted).
• Touch Panel PoE — Passive PoE (48VDC, 7W per IEEE 802.3af) powers a connected touch panel at the table.
• 4K Video with Embedded Audio — HDMI up to 4K 25/30 4:4:4 with embedded audio and HDCP 2.2.
• BYOM USB Link — USB/UVC 2.0 extension lets users host meetings from their own laptop using the room camera and audio.
• No Configuration Required — Plug-and-play installation with all cables and two sets of table brackets included.
• 3-Year Warranty — Limited advance replacement warranty included.

Typical Applications

• Huddle rooms built on Cisco Room Kit Mini or Webex Room USB
• Conference rooms adding wired BYOM connectivity at the table
• Commercial meeting spaces standardizing on USB video bars
• Multi-purpose rooms where table-to-codec cabling must be minimized

Technical Specifications

Frequently Asked Questions

Which devices does the RTK-MINI support?
Any codec or video bar with a standard USB connection, including the Cisco Room Kit Mini and Webex Room USB. USB DisplayLink-enabled devices are not supported — use the RCU3SL USB 3.2 extension instead.

How far can the table be from the codec?
Up to 100 meters (328 feet) over a single CAT5e or CAT6 cable.

Can it power a touch panel at the table?
Yes. Passive PoE per IEEE 802.3af (48VDC, 7W) powers a connected touch panel over the table Ethernet port.

What is the difference between the RTK-MINI and RTK-MINI-X30?
Both use the same TX/RX modules; the X30 kit is cabled specifically for Poly Studio X-Series and V-Series video bars.

Is configuration or programming required?
No. The RTK-MINI is plug-and-play; connect the included cables at each end and the link is transparent to the codec.

What warranty is included?
A 3-year limited advance replacement warranty.
