Shure WA610 4-Way Dual Band Antenna Splitter
The Shure WA610 is a passive 4-way antenna splitter designed for use with GLX-D+ Dual Band wireless systems. It allows a single pair of antennas to feed up to four GLXD4R+ receivers or a combination of receivers and the GLXD+FM Dual Band Frequency Manager. This configuration reduces the total number of antennas required while maintaining reliable signal distribution across 2.4 GHz and 5.8 GHz frequencies.
The splitter is passive, requiring no external power, and includes four 3 m (10 ft) RSMA cables for flexible placement. It is an efficient solution for multi-receiver setups in live sound, installed systems, corporate venues, and houses of worship.
| Feature | Benefit |
|---|---|
| Passive 4-Way Antenna Splitting | Allows one pair of antennas to feed up to four receivers or a combination with the GLXD+FM without requiring power |
| Dual Band Compatibility | Supports both 2.4 GHz and 5.8 GHz frequencies used by GLX-D+ systems |
| Includes Four 3 m RSMA Cables | Provides convenient and flexible connection to multiple receivers and antennas |
| Compact Design | Simplifies multi-receiver setups while reducing antenna clutter |
| No External Power Required | Eliminates additional power supplies and potential failure points |
| Reliable RF Distribution | Maintains signal integrity for improved wireless performance in complex environments |
| Specification | Details |
|---|---|
| Product Type | Passive 4-Way Antenna Splitter |
| Frequency Range | 2.4 GHz and 5.8 GHz |
| Connectors | RSMA |
| Included Cables | Four 3 m (10 ft) RSMA cables |
| Applications | GLXD4R+ receivers and GLXD+FM Dual Band Frequency Manager |
| Mounting | Compact form factor for easy integration |
| Aspect | Shure WA610 | Shure UA221DB-RSMA | Typical Active Splitter |
|---|---|---|---|
| Operation | Passive 4-way | Passive 2-way | Active (requires power) |
| Frequency Support | Dual Band (2.4/5.8 GHz) | Dual Band (2.4/5.8 GHz) | Varies |
| Included Cables | Four 3 m RSMA cables | Two 3 m RSMA cables | Varies |
| Power Requirement | None | None | External power needed |
| Primary Use | Multi-receiver GLX-D+ setups | Two-receiver setups | Larger multi-channel systems |
| Setup Complexity | Simple passive distribution | Simple passive distribution | More components |
FAQ
- What systems is the WA610 compatible with? It is designed for GLX-D+ Dual Band systems, allowing one pair of antennas to feed up to four GLXD4R+ receivers or a combination with the GLXD+FM.
- Does it require power? No, it is a passive splitter and does not need external power.
- How many receivers can it support? It can feed up to four GLXD4R+ receivers or a combination of receivers and the frequency manager.
- What cables are included? Four 3 m (10 ft) RSMA cables are included for easy connection.
- Can it be used with antenna distribution systems? Yes, it is commonly used in multi-receiver setups to reduce the number of required antennas.
- What is the main advantage of using this splitter? It simplifies installations by minimizing antenna count while maintaining reliable signal distribution across Dual Band frequencies.
