Shure RPMDH5B/O-MTQG – DH5 DuraPlex Replacement Boom Arm, Black, MTQG
Product Overview
The Shure RPMDH5B/O-MTQG is the OEM replacement boom arm and cable assembly for the DH5 DuraPlex omnidirectional headset microphone in black, terminated with an MTQG (TA4F-compatible) connector. This is the direct-connect replacement for integrators running DH5 headsets with Shure TA4F wireless bodypack transmitters — including the ULXD1, QLXD1, SLXD1, AD1, and ADX1 — in theater, broadcast, and commercial live event environments. The MTQG termination is the most common Shure bodypack connector, making this the standard replacement part for most commercial DH5 deployments.
Product Description
The RPMDH5B/O-MTQG ships as the complete boom arm, DuraPlex MEMS omnidirectional capsule, and 1.6 mm Plex cable pre-terminated with an MTQG connector using the standard 3-wire wiring design (pin 2 bias, pin 3 audio, pin 1/shell ground) for all Shure TA4F bodypacks. Cable length is 66 inches (1.67 m). The IP57-certified DuraPlex MEMS element provides 20 Hz–20 kHz frequency response, 132 dB SPL maximum, and a 101 dB dynamic range, and resists sweat, moisture, and dust for demanding stage and broadcast use. The black colorway matches the DH5 black headset frame. The boom arm mounts into the DH5 boom pivot and is field-switchable between left and right positioning per the DH5 user guide.
Key Features
- MTQG (TA4F-Compatible) Connector — Direct-connect for all Shure TA4F bodypack transmitters; no adapter required for the majority of Shure wireless systems in commercial AV deployments.
- IP57 DuraPlex MEMS Capsule — OEM MEMS omnidirectional element, 20 Hz–20 kHz, 132 dB SPL max, certified dust resistant and waterproof/sweatproof rated.
- 3-Wire Wiring — Pin 2 bias, pin 3 audio, pin 1/shell ground; standard Shure wiring for correct polarity with all TA4F bodypacks without modification.
- 1.6 mm Plex Cable — Durable cable with no memory effect; 66 in. (1.67 m) length with high-RF immunity for use with digital wireless systems.
- Black Finish — Matches DH5 black headset frame for uniform, low-visibility appearance in theater and broadcast applications.
- Field-Switchable Boom Position — Mounts in DH5 boom pivot; left/right repositioning per DH5 user guide, no tools required.
Technical Specifications
| Specification | Value |
|---|---|
| Compatible Headset | Shure DH5 DuraPlex (Black) |
| Connector Type | MTQG (TA4F-compatible) |
| Wiring | 3-Wire; Pin 2 Bias, Pin 3 Audio, Pin 1/Shell Ground |
| Cable Length | 66 in. (1.67 m) |
| Cable Diameter | 1.6 mm |
| Boom Length | 13.6 cm |
| Microphone Length / Diameter | 14.5 mm / 5.2 mm |
| Net Weight (DH5) | 20.0 g (0.7 oz.) |
| IP Rating | IP57 (dust resistant, waterproof/sweatproof) |
| Capsule Type | MEMS Omnidirectional |
| Frequency Response | 20 Hz – 20 kHz |
| Max SPL | 132.0 dB SPL (1 kHz, 1% THD) |
| Color | Black |
