Shure PA821B-TA Antenna Combiners (470 to 865 MHz) (TAA-Compliant)
Shure PA821B-TA Antenna Combiners (470 to 865 MHz) (TAA-Compliant)
Roll over image to zoom in Click on image to zoom
Shure PA821B-TA Antenna Combiners (470 to 865 MHz) (TAA-Compliant)
Shure PA821B-TA Antenna Combiners (470 to 865 MHz) (TAA-Compliant)
Product Questions? Ask Our Experts!
Tel: 888.230.3661 sales@creationnetworks.net Contact us today for quantity & package discounts!

Shure PA821B-TA Antenna Combiners (470 to 865 MHz) (TAA-Compliant)

Save 20%
Shure SKU: PA821B-TA
No reviews
Price:
$5,179.90 $6,474.60

Description

The PA821B Antenna Combiner from Shure is designed to optimize RF management for Shure PSM Personal Stereo Monitor systems. It can be used when multiple systems are required for monitoring on stage, theater, and rehearsal applications.

The combiner efficiently optimizes up to eight PSM transmitters (sold separately) when racked in a central location, while also reducing rack clutter. It is built with LED indicators for signal overload and signal presence. Additionally, the unit's fan design improves thermal efficiency and ambient noise.

*The TAA-compliant models are made-to-order with a typical delivery time of 2 to 4 weeks. The additional cost of producing separate model variations is reflected in higher pricing compared to standard SKUs.

  • Combines up to Eight PSM Transmitters
  • Improves RF Networking
  • Reduces Rack Clutter
  • Wideband Operation 470 to 865 MHz
  • 8-Input LED Signals
  • LED Indicators for Signal Overload
RF Frequency Range 470 to 865 MHz
Impedance 50 Ohms
Operating Temperature Range 0 to 145°F (-18 to 63°C)
Power Requirements 100 to 240 VAC, 50-60 Hz
Current Drain 1.59 A (referenced at 100 VAC) (159 VA)
Power Consumption 143 W maximum
RF Input Specs
Connector Type BNC
Configuration Active
Impedance 50 Ohms
RF Gain 0 dB (±2 dB)
LED Indicator Minimum Detection Threshold: 2.5 dBm
Overload Threshold: >24 dBm
Main Outputs
Connector Type BNC
Impedance 50 Ohms
Expansion Features
Connector Type BNC
Configuration Passive
Impedance 50 Ohms
Insertion Loss <4 dB
RF Expansion Port Normal Operating Range 33 dBm (2 W)
Dimensions Not specified by manufacturer
Weight Not specified by manufacturer
