Shure NXN5 Nexadyne 5 Supercardioid Dynamic Instrument Microphone
The Shure NXN5 Nexadyne 5 is a supercardioid dynamic microphone optimized for instrument capture in professional live performance and touring environments. It features patented Shure Revonic dual-engine transducer technology, with two precisely calibrated transducers working together to deliver stunning detail, defined lows, natural mid-range, and superior high-end clarity. The supercardioid polar pattern provides optimized off-axis rejection to minimize bleed from other instruments while isolating the full, authentic sound of the source.
The compact dynamic cartridge design and included A25D stand adapter enable versatile positioning on stands or clips. A discreet black finish keeps the microphone low-profile on stage, and the rugged construction withstands the demands of professional touring and performance.
| Feature | Benefit |
|---|---|
| Revonic Dual-Engine Transducer Technology | Delivers stunning detail through two precisely calibrated transducers working together |
| Supercardioid Polar Pattern | Provides optimized off-axis rejection to minimize bleed from other instruments |
| Compact Dynamic Cartridge Design | Ideal for guitar amps, brass, woodwinds, and other instruments with minimal visual impact |
| Included A25D Stand Adapter | Allows quick and stable positioning on standard mic stands |
| Defined Lows, Natural Mids, Superior Highs | Captures the full, authentic sound of instruments with clarity and punch |
| Rugged Construction | Built to withstand the demands of professional touring and live performance |
| Discreet Black Finish | Maintains a low-profile appearance on stage |
| Specification | Details |
|---|---|
| Microphone Type | Dynamic |
| Polar Pattern | Supercardioid |
| Frequency Response | 40 Hz – 16 kHz |
| Output Impedance | 335 ohms |
| Sensitivity | -61 dBV/Pa (0.9 mV/Pa) |
| Connector | XLR 3-pin male |
| Color | Black |
| Weight | 0.54 lb (245 g) |
| Included Accessories | A25D stand adapter, travel bag |
| Aspect | Shure NXN5 | Shure SM57 | Typical Instrument Microphone |
|---|---|---|---|
| Transducer Technology | Revonic dual-engine | Single dynamic | Single dynamic or condenser |
| Polar Pattern | Supercardioid | Cardioid | Cardioid or supercardioid |
| Frequency Response | 40 Hz – 16 kHz (instrument-optimized) | 40 Hz – 15 kHz | Varies |
| Primary Application | Guitar amps, brass, woodwinds, percussion | General instrument | Instrument-specific |
| Off-Axis Rejection | Optimized supercardioid | Good cardioid | Varies |
| Mounting | A25D stand adapter included | Standard clip | Clip or stand mount |
FAQ
- What instruments is the NXN5 designed for? It is optimized for guitar amps, brass, woodwinds, percussion, and other instruments requiring detailed, isolated capture.
- What is Revonic dual-engine technology? It uses two precisely calibrated transducers working together for enhanced detail, natural response, and superior performance.
- Does it include a mount? Yes, it comes with the A25D stand adapter for quick and stable positioning.
- Is it suitable for touring? Yes, its rugged construction and discreet black finish make it ideal for professional live performance and touring.
- How does the supercardioid pattern help? It provides excellent off-axis rejection to minimize bleed from other instruments on stage.
- What is the frequency response? It covers 40 Hz to 16 kHz, tailored for clear, full instrument sound with defined lows and natural mids.
