Shure MXA310AL Table Array Microphone (Aluminum)
The Shure MXA310AL is a premium tabletop array microphone from the Microflex Advance series, designed for clear speech capture in conference rooms, boardrooms, huddle rooms, and multi-purpose spaces. It features Steerable Coverage technology with up to eight independent channels, each with selectable polar patterns (including the unique toroid pattern), allowing precise aiming based on seating arrangements for excellent off-axis rejection and reduced room noise.
The low-profile aluminum design blends discreetly into modern conference tables. It uses Dante/AES67 networked audio with PoE power for simple single-cable installation. Onboard IntelliMix DSP provides automatic mixing, low-cut filter, and per-channel processing, reducing the need for external equipment.
| Feature | Benefit |
|---|---|
| Steerable Coverage Technology | Up to 8 independently steerable channels with selectable polar patterns for precise coverage |
| Toroid Polar Pattern Option | Captures sound from the table perimeter while rejecting overhead noise |
| Low-Profile Aluminum Design | Discreet placement on conference tables |
| Dante/AES67 Networked Audio | Single-cable installation for audio, control, and power via PoE |
| Onboard IntelliMix DSP | Automatic mixing, low-cut filter, and per-channel EQ/mute/gain |
| TAA Compliant | Meets U.S. government procurement requirements |
| Specification | Details |
|---|---|
| Microphone Type | Tabletop Array Microphone |
| Channels | 8 (4 independent transmit + 1 automix output) |
| Polar Patterns | Cardioid, Hypercardioid, Supercardioid, Toroid, Omnidirectional, Bidirectional (per channel) |
| Frequency Response | 100 Hz – 20 kHz |
| Sensitivity | –21 dBFS/Pa (at 1 kHz, –15 dB gain) |
| Maximum SPL | 115.2 dB SPL (1 kHz at 1% THD, –15 dB gain) |
| Self Noise | 19.2 dB SPL-A (Cardioid, –15 dB gain) |
| Connector | RJ45 |
| Power Requirement | PoE (Class 0) |
| Dimensions | 3.6 × 13.4 × 13.4 cm (1.4 × 5.3 × 5.3 in) |
| Weight | 362 g (0.8 lbs) |
| Color | Aluminum |
| Applications | Conference rooms, boardrooms, huddle rooms |
| Compatibility | Microflex Ecosystem, Microsoft Teams, Zoom Rooms |
| Aspect | Shure MXA310AL | Shure MXA310W | Shure MXA920W-S |
|---|---|---|---|
| Form Factor | Tabletop array | Tabletop array | Square ceiling array |
| Coverage Technology | Steerable Coverage | Steerable Coverage | Automatic Coverage + steerable lobes |
| Channel Count | 8 channels | 8 channels | 8 channels |
| Primary Use | Table-based meetings | Table-based meetings | Large/medium rooms |
| Installation | Tabletop | Tabletop | Drop ceiling |
| DSP | Onboard IntelliMix | Onboard IntelliMix | Onboard IntelliMix |
FAQ
- What applications is the MXA310AL best suited for? It is ideal for conference rooms, boardrooms, and huddle spaces where clear table-based speech capture is required.
- How many channels does it support? It provides 8 channels with independently steerable coverage and selectable polar patterns.
- Is networking required? Yes, it uses Dante/AES67 for single-cable installation via PoE.
- Does it include onboard DSP? Yes, it features IntelliMix DSP with automatic mixing and low-cut filter.
- Is it TAA compliant? Yes, this aluminum variant is TAA compliant for U.S. government procurement.
- Is it compatible with major conferencing platforms? Yes, it integrates seamlessly with the Microflex Ecosystem and supports Microsoft Teams, Zoom, and other platforms.
