Sennheiser XSW-D PRESENTATION BASE SET Presentation base set - 508492

Product Overview

The Sennheiser XSW-D PRESENTATION BASE SET is a digital wireless set for fixed presentation environments, including conference rooms, lecture halls, and corporate AV installations. The set includes a bodypack transmitter with 3.5 mm input and a presentation-oriented receiver, operating on license-free 2.4 GHz digital wireless without the need for UHF frequency coordination or licensing. The microphone is not included, allowing integrators to pair it with the appropriate lavalier or headworn capsule for the specific application. At $319, it provides the XSW-D wireless platform in a configuration suited to permanent or semi-permanent installation.

Product Description

The XSW-D PRESENTATION BASE SET delivers the core XSW-D transmitter and receiver pair in a configuration optimized for presentation and installation applications where the receiver connects to a fixed audio system rather than a portable camera or recorder. The bodypack transmitter accepts 3.5 mm locking connector microphones including the ME 2-II lavalier and ME 3-II headworn, which are available separately for use with this set. Automatic 2.4 GHz channel management provides license-free wireless operation with no setup complexity — the system selects an available channel automatically on power-up. USB-rechargeable batteries provide approximately 5 hours of operation per charge. The PRESENTATION BASE SET is the correct choice for AV integrators installing wireless presenter microphone systems in conference rooms, boardrooms, lecture halls, and similar fixed-installation environments where the transmitter-receiver pair is needed without a specific bundled microphone.

Key Features

• Presentation-Optimized Receiver — Configured for fixed AV installation in conference rooms and lecture halls.
• Bodypack Transmitter with 3.5 mm Input — Compatible with ME 2-II lavalier, ME 3-II headworn, and other 3.5 mm locking connector microphones (sold separately).
• 2.4 GHz License-Free Digital Wireless — No frequency licensing or coordination; automatic channel selection.
• Uncompressed Digital Audio — Clean signal with low latency for presentation audio.
• USB Charging — Rechargeable transmitter and receiver; USB cable included.
• Microphone Not Included — Base set for pairing with separately sourced Sennheiser ME 2-II or ME 3-II microphone.
• XSW-D Platform Compatible — Components are individually compatible with other XSW-D units for custom configurations.

Typical Applications

• Conference room wireless presenter microphone installation
• Corporate boardroom AV wireless
• University and lecture hall presenter wireless
• House of worship fixed wireless microphone installation
• Training room and classroom instructor wireless

Technical Specifications

Frequently Asked Questions

Which microphone should I add to the PRESENTATION BASE SET?

The ME 2-II omnidirectional lavalier is the most common choice for clip-on presentation use. The ME 3-II cardioid headworn microphone is appropriate for applications where consistent mouth distance and higher feedback rejection are priorities. Both connect via 3.5 mm locking connector and are available separately on creationnetworks.net.

How does the PRESENTATION BASE SET differ from the PORTABLE BASE SET?

The PRESENTATION BASE SET uses a receiver configured for fixed installation in AV systems, while the PORTABLE BASE SET uses a compact receiver with 3.5 mm TRS output oriented toward cameras and portable recorders. Select the appropriate set based on the intended receiver connection type and installation context.

Does the XSW-D require a specific network or IT coordination for 2.4 GHz operation?

No. The XSW-D operates autonomously on the 2.4 GHz ISM band with automatic channel management and does not require network registration, IP configuration, or IT coordination.
