Sennheiser XSW-D INSTRUMENT BASE SET Instrument base set - 508493

Product Overview

The Sennheiser XSW-D INSTRUMENT BASE SET is a compact digital wireless instrument set for electric guitar, bass, and other 6.3 mm jack instrument sources. Operating on license-free 2.4 GHz digital wireless, the set includes a plug-on transmitter and a receiver with 6.3 mm jack output, providing direct instrument-to-amp connectivity without cables or adapters. USB charging and uncompressed digital audio transmission make this set appropriate for musicians who need a simple, high-quality wireless solution without the complexity or licensing requirements of UHF analog systems.

Product Description

The XSW-D INSTRUMENT BASE SET is designed to eliminate the instrument cable between guitar or bass and amplifier with minimal setup and no frequency coordination required. The transmitter plugs directly into the instrument's output jack — no bodypack or belt clip required — and the receiver outputs the audio signal via 6.3 mm jack directly to an amplifier input. The 2.4 GHz digital wireless link provides uncompressed audio with low latency appropriate for live performance, preserving the tone of passive and active instrument pickups without the coloration or signal loss associated with cable capacitance over long runs. The license-free 2.4 GHz band eliminates the frequency licensing required for UHF wireless operation in some markets and removes the need for frequency coordination and scanning during setup. The system operates on USB-rechargeable batteries with a charging cable included. The compact plug-on transmitter design eliminates the need for a belt-worn bodypack, making it particularly convenient for guitarists and bassists who prefer minimal stage equipment. The XSW-D INSTRUMENT BASE SET is compatible with other XSW-D components, allowing the transmitter or receiver to be used in combination with other XSW-D units for custom configurations.

Key Features

• Plug-On Transmitter — Connects directly to 6.3 mm instrument output jack; no bodypack or belt clip required.
• 6.3 mm Jack Receiver Output — Direct connection to amplifier or pedal input without adapters.
• 2.4 GHz License-Free Digital Wireless — No frequency licensing or coordination required; automatic channel selection.
• Uncompressed Digital Audio — Full signal quality from instrument to amplifier with low latency for live performance.
• USB Charging — Rechargeable batteries on both transmitter and receiver; USB charging cable included.
• Compact Design — Plug-on transmitter eliminates bodypack for minimal stage clutter.
• XSW-D Component Compatible — Transmitter and receiver are individually compatible with other XSW-D components for custom builds.

Typical Applications

• Electric guitar and bass wireless for live performance
• Rehearsal room and practice instrument wireless
• House of worship guitar and bass stage setups
• Small venue and club stage instrument wireless
• Studio tracking with wireless instrument connection

Technical Specifications

Frequently Asked Questions

Does the XSW-D require frequency coordination or licensing?

No. The XSW-D operates on the license-free 2.4 GHz band and uses automatic channel selection, eliminating the frequency scanning and coordination required by UHF analog wireless systems and the licensing required for UHF operation in some markets.

What is the latency of the XSW-D digital system?

The XSW-D is designed with low latency appropriate for live instrument performance. Sennheiser specifies the audio latency for the XSW-D at approximately 3.4 ms, which is below the threshold typically perceptible to performers in live stage conditions.

Can I use the XSW-D transmitter with a different XSW-D receiver?

Yes. XSW-D transmitters and receivers are sold as individual components as well as sets, and compatible XSW-D units can be mixed within the system. The INSTRUMENT TX can be paired with any compatible XSW-D receiver.

How long does the battery last per charge?

Battery runtime for XSW-D components is approximately 5 hours per full charge under typical operating conditions. A USB charging cable is included with the set.

Will 2.4 GHz Wi-Fi interference affect the XSW-D?

The XSW-D's automatic frequency management is designed to select available channels and avoid congested Wi-Fi frequencies within the 2.4 GHz band. In environments with very dense Wi-Fi or other 2.4 GHz devices, some performance reduction is possible; for such environments, a UHF analog wireless system may be more appropriate.
