Sennheiser EW-DX EM 2 (V5-7) 2 channel half-rack (9,5“) non-Dante® receiver - 509352
Sennheiser EW-DX EM 2 (V5-7) 2 channel half-rack (9,5“) non-Dante® receiver - 509352 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Sennheiser EW-DX EM 2 (V5-7) 2 channel half-rack (9,5“) non-Dante® ...
Product Overview
The Sennheiser EW-DX EM 2 (V5-7) is a professional two-channel half-rack digital wireless receiver in the V5-7 band (823–865 MHz) without Dante networking. It forms the receiving core of an EW-DX two-channel wireless system, offering ultra-low latency digital audio, AES 256 encryption, and True Diversity reception. Available at Creation Networks for professional live sound and broadcast applications.
Product Description
The EW-DX EM 2 (V5-7) is a two-channel half-rack digital wireless receiver that delivers the premium performance of Sennheiser's EW-DX platform without the Dante networking module. Operating in the V5-7 band (823–865 MHz), it provides license-free UHF wireless reception with digital RF technology. True Diversity reception with two antennas minimizes signal dropouts in complex environments. Audio latency is below 1.6 ms, enabling seamless in-ear monitor integration. AES 256 encryption secures the audio transmission against interception. The receiver outputs via XLR balanced analog outputs for two channels. It supports up to 90 simultaneous channels in a single frequency band, making it ideal for large systems. The EW-DX EM 2 is compatible with all EW-DX SK, SKM-S, and SKM transmitters in the V5-7 band. For networked Dante audio distribution, the EW-DX EM 2 DANTE variant is also available at Creation Networks.
Key Features
- Two-Channel Digital Wireless Receiver — Receives two EW-DX transmitters simultaneously.
- V5-7 Band (823–865 MHz) — License-free UHF digital wireless operation.
- True Diversity Reception — Dual antenna/tuner for dropout-resistant performance.
- Ultra-Low Latency (<1.6 ms) — Suitable for IEM and live mixing without perceptible delay.
- AES 256 Encryption — Secure digital audio for broadcast and corporate use.
- Up to 90 Simultaneous Channels — High channel density without intermodulation.
- Half-Rack Form Factor — Two units fit in 1U with appropriate rack hardware.
- Non-Dante Version — Balanced XLR analog outputs; Dante version available separately.
Typical Applications
- Two-channel vocal wireless systems for touring and installed sound
- Broadcast television dual-talent wireless microphone systems
- Corporate conference dual-presenter wireless audio
- Houses of worship two-channel wireless with encryption
- Theatre productions requiring digital wireless precision
Technical Specifications
| Channels | 2 |
|---|---|
| Frequency Band | V5-7 (823–865 MHz) |
| Diversity | True Diversity |
| Latency | <1.6 ms |
| Encryption | AES 256 |
| Audio Output | XLR balanced (2x) |
| Form Factor | Half-rack (9.5") |
| Dante | No (see EW-DX EM 2 DANTE for Dante version) |
Frequently Asked Questions
- What is the difference between this and the EW-DX EM 2 DANTE?
- This version has standard balanced XLR analog outputs only. The DANTE version adds Dante network audio output for integration with Dante-enabled audio systems.
- What transmitters are compatible with the EW-DX EM 2 (V5-7)?
- Compatible with EW-DX SK, EW-DX SKM-S, and EW-DX SKM transmitters in the V5-7 band.
- How does it fit in a rack?
- The EW-DX EM 2 is a half-rack unit (9.5"). Two units can be mounted side-by-side in a 1U space with appropriate half-rack mounting hardware.
- Can I use rechargeable batteries with the transmitters?
- Yes, EW-DX transmitters support BA 70 lithium-ion rechargeable batteries charged via L 70 or CHG 70N chargers.
- How many channels can I run simultaneously?
- The EW-DX platform supports up to 90 simultaneous channels without intermodulation interference in a given band.
